2-PC Flanged End Pneumatic Actuated Ball Valve with ISO5211 Standard for DN15-DN300 Industrial Applications

Specifications

MOQ :

Connection Form :

Flange

Driving Mode :

Pneumatic

Nominal Pressure :

PN1.0-32.0MPa

Channel Type :

Straight Through

Valve Structure :

Floating Ball

Valve Size :

1/2"~12" (DN15~DN300)

Body Material :

WCB, CF8, CF8M, CF3M

Seat Material :

PTFE, RTFE, Graphite & Others

Pressure Rating :

DIN: PN10~PN40, ANSI: 150#~600#

Air Supply :

40-100psig

Air Connection :

1/4"

Temperature Range :

Normal Temperature

Valve Type :

2-PC Flanged End Ball Valve

Function :

Blow-Down, Relief, Atmospheric

Production Capacity :

50000PC/Y

Description

VS series pneumatic actuated ball valve (2-PC FLANGED END):
Valve: 2-PC Flanged End Ball Valve (two way)
Valve Size: 1/2"~12" (DN15~DN300)
Body/ Ball Material: WCB, CF8, CF8M, CF3M
Seat Material: PTFE, RTFE, Graphite & Others
Rating: DIN: PN10~PN40
ANSI: 150#~600#
Connection: Flanged End
