Applications

Horizontal Pneumatic Butterfly Valve

Butterfly valve both manual and automatic operation can be used in industrial applications in fluid products, such as food processing, pharmaceutical and chemical industries.

Technical Specifications

Size: DN10-DN300, 1/2 -12 "
Temperature: 130ºC
Pressure: 10bar
Material: ASTM T304/T316L, 1.4301/1.4404
Connection: flange, Weld, Clamp, Thread, etc.
Operation standard: DIN SMS RJT 3A ISO IDF
Pneumatic Operation: Single action, Double action

A horizontal pneumatic butterfly valve is a specific type of valve that utilizes a pneumatic actuator to control the flow of fluids in a horizontal pipeline. Here's some information about horizontal pneumatic butterfly valves:

Function	Regulate or shut off the flow of fluids in horizontal pipelines
Butterfly Valve Type	Utilizes a rotating disc or plate to control the flow
Actuation	Equipped with pneumatic actuators for automated operation using compressed air or gas
Design	Designed for horizontal installation with a compact and low-profile body
Sealing	Resilient seals ensure a tight seal when the valve is closed, preventing leakage and backflow
Flow Control	Valve's disc rotation allows for precise flow control and throttling capabilities
Control Signal	Pneumatic actuators receive control signals for position control from a centralized system or operator
Advantages	Easy installation, reliable sealing, precise control, and remote operation
Maintenance	Generally require minimal maintenance, but regular inspection and servicing are recommended
