PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
Specifications
Brand Name :
FESTO
Model Number :
VRPA-CM-Q4-E
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD50-60
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
500 pcs per month
Delivery Time :
5-7working days
Packaging Details :
Plastic bag, Carton
Type :
VRPA-CM-Q4-E
Part no :
8086003
Brand :
FESTO
Material housing :
PBT
Weight :
23 g
Note on materials :
RoHS-compliant
Description

FESTO Pressure regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676

About product

Regulates the operating pressure independently of the fluctuating inlet pressure

With secondary exhaust and with return flow function

Piston regulator with through pressure supply

Technical Data

Pneumatic connection, port 1 QS-4
Pneumatic connection, port 2 QS-4
Type of mounting With through-hole
Standard nominal flow rate 80 l/min
Ambient temperature 0°C-60°C
Material housing PBT
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Mounting position optional
Type of actuation Manual
Adjustment component Rotary knob with detent
Symbol 00991558
Pressure gauge (ANALOG) or Pressure display (DIGITAL) With pressure gauge
Pressure regulation range 0.1 MPa ... 0.8 MPa
Pressure regulation range 1 bar ... 8 bar
Pressure regulation range 14.5 psi ... 116 psi
LABS (PWIS) conformity VDMA24364-B2-L
Product weight 23 g
Note on materials RoHS-compliant
Material static seals NBR

General technical data

PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676

There are many models. Please hurry to me!
