Mirror Polish High Precision Injection Mold 1 - 32 Cavities Custom Injection Molds
Mirror Polish High Precision Injection Mold 1 - 32 Cavities Custom Injection Molds
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Product name :
High Precision Injection Mold
Product material :
Plastic,Steel,PP,ABS,PS
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Product :
Vehicle Mould,Household Appliance,plastic injection mold,injection machine mold,Household Product
Material :
STEEL,ps,PP,Steel and metal,aluminum
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Runner :
Hot Runner\ Cold Runner,cold/hot
Cavity :
Multi Cavity,as per client's requirement
Mold material :
NAK80,H13,50#,P20,45#
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Mold life :
000 to 1,500000 shots,000 shots,100000-1000000,50
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Plastic material :
Peek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
Size :
as samples/drawings,customized accepted,Customized Size
Description
High-Precision Injection Mold
Product Process

The high-precision mold utilizes five-axis machining and EDM technology. Manufacturing tolerances can be controlled to ±0.01mm, making it suitable for producing high-precision parts.

Product Parameters
Parameter Name Parameter Description
Mold MaterialS136 8407
Number of Cavities1–32
Product Size Range1mm–100mm
Injection Molding Machine Capacity30T–500T
Cooling MethodHigh-efficiency water cooling
Injection Pressure100–1800bar
Service Life500,000–1,000,000 cycles
Surface TreatmentMirror Polish
Mold TypeHigh-Precision Mold
Applicable MaterialsPOM, PA, PC
Applications
  • Micro Gears
  • Precision Connectors
  • Medical Consumables
  • Electronic Sensor Housings
Product Advantages
  • Extremely High Dimensional Accuracy
  • Excellent Surface Finish
  • High Product Consistency
  • Suitable for Micro-Products
FAQ
Q: Can we mass-produce micro parts?
A: Yes Suitable for high-precision mass production
Q: Is the mold lifespan shortened?
A: No, the material selection ensures a long lifespan.
Customized mold customization

We can design customized cooling and gating systems based on customer part tolerance requirements.
