Vertical Injection Moulding Machine For Plastic Plugs
Vertical Injection Moulding Machine For Plastic Plugs
Specifications
Brand Name :
LIZHU
Model Number :
LZ-D
Certification :
CE, CSA
Place of Origin :
CHINA
MOQ :
1set
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
10 pcs/month
Delivery Time :
7-10days
Packaging Details :
Carton Packing
Name :
Precision Injection Molding Machine
Max Clamping Force :
2000tons
Injection Weight :
130grams
Injection Speed :
370mm/s
Condition :
New
Brand :
LIZHU Machine
Description

Vertical Injection Moulding Machine For Plastic Plugs

1. Description:


1. A vertical direct hydraulic clamping system designed specifically for insert molding is intended for precise, secure operation.
2. With a double sliding table or rotational design, you can remove items while also finishing molding. This improves manufacturing safety and efficiency while cutting costs.
3.Low-pressure mold clamping, heavy-duty tie-bars, and a high precision mold platen (Parralelism/flatness: 0.01/100mm) all help to extend machine and mold life.
4.Nitride and NIP/nitroflon-coated screws and barrels are long-lasting, strong, and resistant to acid and alkali.

2. Sepcifications:

Item Unit LZ-D
Injection Unit Screw Diameter mm Ø25 Ø28 Ø30
Injection Pressure Kg/cm2 2131 1312 1215
Theoretical Shot Volume cm3 214 263 309
Shot Weight(PS) g 171 256 247
oz 6.3 7.3 9.5
Injection Rate cm3/sec 167 225 217
Screw Stroke mm 135
Screw Rate rpm 0-250
Injection speed mm/s 122
Nozzle Stroke mm 380
Clamping Force Clamping Force tons 30
Opening Force tons 15
Sliding Plate Size mm 550*533
Plate Size mm 585*1280
Rotary Table Diameter mm -
Sliding Table Stroke mm -
Max Mold Size mm 595*360
Min Mold Thickness mm 300(50+50)
Opening Stroke mm 230
Max Opening Stroke mm 550(50+50)
Position tolerance mm ±0.02
Ejector Unit Ejector Stroke mm 50/113
Ejector Force Tons 7
Ejector Diameter mm 20
Ejector PCS. pcs 1
Hybrid Unit Oil Tank Volume liters 155
Cold Water Volume Liters/min 163
Servo Motor kw 20
Heating Volume kw 15
Total Wattage kw 30
Others Machine Weight tons 5.2
Machine Size m -

3. Machine Features:


1) The clamping unit is formed of a screw rod and nuts; performance is increased by decreasing the clamping cylinder stroke.

2) The working height is lower than in standard designs.

3) All insert components are included.

4. Pictures:

5. FAQ:

1) Are you a manufacturer or a trading company?

We are professional vertical injection molding machine manufacturer in China.

2) Why Choose you?

We have high quality, professional team, good service, and competitive prices.

3) How can you guarantee quality?

Our professional team will give good suggestion and designing before start production, and always final Inspection before shipment.

4) Do you accept my own design?

We can provide OEM/ODM service.

5)When can I get my machine after I paid?

We will deliver the machines on time as the date we agreed.
