Hzs25-75 M3/H Concrete Batching Plant Mixing Plant
Hzs25-75 M3/H Concrete Batching Plant Mixing Plant
Hzs25-75 M3/H Concrete Batching Plant Mixing Plant
Hzs25-75 M3/H Concrete Batching Plant Mixing Plant
Specifications
Brand Name :
SUNNY
Model Number :
HSZ100
Place of Origin :
Hunan
MOQ :
1 set
Price :
USD 110000-150000/ SET
Payment Terms :
L/C,T/T,D/P,Western Union,MoneyGram
Supply Ability :
20 Set/Sets per Month
Delivery Time :
25-30 days
Packaging Details :
container
Maaterial :
cement, crushed stone, sands and so on
Application :
Building Works,Construction Projects,bridges,docks,airport
Control system :
automatic PLC control,totally automatic
Productivity :
≤60m3/h
Mixer :
JS2000 Twin-shaft Concrete Mixer
Warranty :
12 Months
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support,Field installation,commissioning and training
Description
Heavy-Duty Construction Concrete Batching Plant: Batching Plant Built For Tough Jobs Hzs25 M3/H
Product Specifications
Material cement, crushed stone, sands and so on
Application Building Works, Construction Projects, bridges, docks, airport
Control system automatic PLC control, totally automatic
Productivity ≤60m³/h
Mixer JS2000 Twin-shaft Concrete Mixer
Warranty 12 Months
Condition New
After-sales service Engineers available to service machinery overseas, Online support, Video technical support, Field installation, commissioning and training

Applications of HZS25 Batching Plant

  • Residential housing and villas
  • Rural road and bridge construction
  • Precast concrete product factories
  • Municipal infrastructure projects
  • Small to medium-sized commercial jobs
HZS25 Bucket Type Batching Plant

The HZS25 Concrete Batching Plant is a compact, high-performance solution designed for efficient and reliable concrete production. With a capacity of 25 cubic meters per hour, this plant is perfect for small to medium-scale construction projects like residential buildings, roads, and bridges. Its space-saving design and user-friendly operation make it an excellent choice for contractors who need a reliable, cost-effective batching system.

Key Features
  • Bucket Feeding System: The plant utilizes a bucket system to feed aggregates and other materials into the weighing hoppers, ensuring precise and consistent batching.
  • Twin-Shaft Mixer: A high-efficiency twin-shaft mixer ensures thorough mixing of all ingredients, resulting in a homogeneous concrete mix with excellent properties.
  • Weighing System: Accurate weighing systems for aggregates, cement, water, and additives guarantee precise dosing and consistent concrete quality.
  • Control Panel: A user-friendly control panel provides easy operation and monitoring of the entire batching process.
  • Modular Design: The plant's modular design allows for easy installation and transportation, making it suitable for various site conditions.
Model Specifications
Model HZS35 HZS50 HZS75 HZS100
Production in Theory (m³/h) 35 50 75 100
Mixer Type JS750 JS1000 JS1500 JS2000
Mixing Motor Power (KW) 2×15 2×18.5 2×30 2×37
Cycle time(S) 60 60 60 60
Mixer Discharging Volume(L) 750 1000 1500 2000
Maximum Particle Size of Aggregate(mm) 60 60 60 80
Batching Volume(L) 1200 1600 2400 3200
Aggregate Species 2-3 2-4 4 4
Aggregate lifting motor power(kw) 7.5 15 18.5 22
Discharging Height (m) 4 4 4 4
Installed Capacity(KW) 50 70 110 120
Hzs25-75 M3/H Concrete Batching Plant Mixing Plant
Advanced Features
  • Combined structure and unitized module design for quick installation and demolition
  • Increased unloading angle of aggregate bin prevents unloading difficulties during rain
  • Cylinder discharge or electric push rod for convenient and quick material discharge
  • High-quality steel construction for strong structural strength and stability
  • Twin-shaft forced mixing delivers superior mixing performance and uniformity
  • Premium pneumatic and electrical components ensure reliability and accurate metering
  • Comprehensive maintenance access with walking platforms and check ladders
  • Environmental protection features including pulse dust removal and wastewater recycling
