Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Specifications
Warranty :
1 year, 2 Year
Place of Origin :
China
Brand Name :
Umot
Model Number :
42HSC1409
Phase :
2
Type :
Hybrid, Reduction Motor
Current / Phase :
1.33A
Product name :
Worm Gear Reducer Stepper Motor
Brand :
Umot
Motor Size :
42x34mm
Material :
pure copper
Maximum allowable radial load :
200N
maximum allowable shaft load :
100N
Backlash (Without Load) :
1°-1.5°
Application :
Sorting equipment/Plasma detector
Packaging Details :
Waterproof membrane + foam + carton / wooden box
MOQ :
20 pieces
Price :
$29.95/pieces 20-199 pieces
Description
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Product Name
Worm Gear Stepper Motor
Motor Model
42mm Nema17
Motor Size
42x34mm
Worm Gear Materil
Pure cupper
Max.Radial Load
200N
Max.Shaft Axial Load
100N
Rated Voltage
2.93V
Rated Current
1.33A
Resistance
2.2Ω
Holding Torque
270mN.m
Rotor Inertia
30g.cm2
Reduction Ratio
17/31/50/100/290/505 :1
Backlash
1°-1.5°
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
Umot High Torque Height 34mm Nema17 Worm Geared Reducer Stepper Motor with Gearbox
