Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder
Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder
Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder
Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder
Specifications
Brand Name :
LTPM CHINA
Model Number :
DPP-Series
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
25 SETS Per month
Delivery Time :
25days
Packaging Details :
wrapped with strech film packed into Export Standard Wooden case, this package afford long time sea shipment and anti moisture.
Overall Dimension :
1800*460*1070mm
Feeding: :
Universal feeder
PVC hard Film :
0.15-0.5*110 (mm)
Air Pressure(Mpa) :
0.6-0.8MPa
Total Power :
380V/220V 50Hz 4.5Kw
Punch frequency :
10-33times/min
Production capacity(pcs/h) :
2400-9600
Weight(kg) :
500Kg
Description

1. This machine adopts the latest model of high-power transmission, the row chain drive the transmission shaft, which eliminates the other gear transmission error and noise.

2. Electrical adopts the imported control systems, which can be customizing by the user. Equipped with the short shot up leakage device, missing particle detection and removed device (Omron Sensor). Adopts imported inverter.

3. This machine adopts optoelectronic system: PVC, PTP, tropical aluminum packaging and automatic feeding, waste selvage automatic material receiving device, which ensure the long-distance multi-site synchronization stability.

4. This machine adopts sub-portfolio structure: PVC informing, feeding,hot sealing; Tropical aluminum cold forming, hot sealing, blanking

5. This machine can be equipped with re-provision photoelectric detection and corrected device, equipped with imported stepper motor, photo printing and packaging, which will optimize the grades of packaging.

6. Application: capsule, tablets, pill, injection and other medicine and food, electronic components blister sealed packaging.

Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder

Main Technical Parameters

Blanking 10-35 time/min
Production Capacity 2100 version/h
Max. forming area and depth 110*90*15(mm)
Standard Stroke 20-70mm (It can be designed by users.)
Standard Forum 80*57mm (It can be designed by users.)
Air Pressure 0.6-0.8MPa
Total Power 380V/220V 50Hz 4.5Kw
Main Electrode Power 0.75Kw
Outline dim. 1800*460*1070mm
Weight (Kg) 500Kg
Noise Index <75dBA

Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder

Alu Tablet Blister Packing Machine Capsule Pill Sealing Forming Universal Feeder

Company Profile
Our Company
- Since year 1996, LTPM CHINA had started manufacturing Pharmaceutical and food packaging machines such as Capsule Filling Machine, Ampoule Filling and Sealing Machine, Blister Packaging Machine, Pill Counting and Bottling Line, Cartoning Machine, Bag Packaging Machine, Liquid Filling and Capping Machine etc. - LTPM CHINA designs different types of packaging lines for customers, including standard or non-standard models. - LTPM CHINA's machinery = high automation + high precision + more energy saving + satisfactory warranty and after-sales service + trusted brand
Our Workshop
FAQ
Q: What is the warranty period for your machine?
A: 5 years free warranty.

Q: Are you a real factory/manufacturer?
A: Of course. Our factory is inspected by third party. We much welcome you to visit us and free to pick you up form hotel. You don't have time? We can use live video and you can visit us on line.

Q: Is engineer available to serve oversea?
A: Yes, we can send engineers to your factory but all the fee will be on buyers. In order to save your cost, we will send you a video of full details machine installation and assist you till the end.

Q: How can we make sure about the machine quality after placing the order?
A: Before delivery, we will running half hour of the machine to checking the stability and sending you the testing video until you sastisfy. We will setting all the parameters well. And also you can arrange for quality checking by yourself or by your contacts in China.

Q: We are afraid you won't send us the machine after we send you the money?
A: We have our business license and certificate. And it is available for us to use alibaba trade assurance service, protect your money, machine qulaity and delivery are guaranted.
