ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation
ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation
Specifications
MOQ :
1
Payment Terms :
T/T
Delivery Time :
5-30 word days
Layer :
4L
Material :
Al
Board Thickness :
2.0mm
Min. Hole Size :
0.20mm
Pin Space :
0.20mm
Surface Finish :
SMT
Testing Method :
Flying Probe/AOI/FCT
Application :
Traffic lights
Service :
One-stop Service,PCB&PCBA,ODM and OEM
Description

Efficient Heat Dissipation Lighting PCB Assembly Suitable for High-power Lamps

♦ What is Lighting PCB Assembly?

​​Lighting PCB Assembly is a specialized electronic assembly that integrates circuit boards with lighting components (e.g., LEDs, drivers) and control systems. It serves as the core functional unit in diverse lighting applications, combining electrical connectivity, thermal management, and intelligent control to enable efficient, durable, and feature-rich lighting solutions.

♦ Features of Lighting PCBA:

    • ​​Intelligent Control​​: Equipped with smart sensing (e.g., auto on/off via human proximity detection) and remote functionality, including dimming, scheduling, and scene presets. Enables full-home smart control via mobile app or voice commands.

    • ​​Dimming & Speed Regulation​​: Delivers precise light intensity and device speed adjustment for optimal comfort.

    • ​High Sensitivity​​: Advanced sensor PCBAs ensure rapid and accurate human motion detection.

    • ​​Elegant Design​​: Aesthetically optimized to seamlessly integrate with diverse interior environments.

♦ Applications of Lighting PCBA:

    • Precise structure: Contains core components such as LED lights, power cords, and controllers, and the brightness and color of LED lights are precisely controlled by the controller.
    • ​​Various substrates: Common substrate materials include aluminum substrates, copper substrates, iron substrates, and fiberglass substrates. Aluminum substrates have excellent thermal conductivity and are suitable for high-power LED lighting fixtures, which is conducive to efficient heat dissipation and improves the stability and life of the lamps.
    • ​​Excellent performance: SMT (surface mount technology) is used to accurately weld LED lamp beads, which has the characteristics of high brightness, stable performance, long service life, energy saving, and environmental protection

♦ Technical Parameters

PCB Assembly Capability

Item

Normal

Special

SMT

Assembly

PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm, W≥3mm

L＜2mm

Maximum

L≤800mm, W≤460mm

L ＞ 1200mm, W＞500mm

Thickness( T)

Thinnest

0.2mm

T＜0.1mm

Thickest

4 mm

T＞4.5mm

SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm＜T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch＜0.4mm

CSP/ BGA

Min ball space

0.5mm

0.3mm≤Pitch＜0.5mm

DIP

Assembly

PCB specification

Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L＜50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mm, W≥500mm

Thickness( T)

Thinnest

0.8mm

T＜0.8mm

Thickest

3.5mm

T＞2mm

♦ One-Stop PCBA Solution

ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation ODM Street Light Led Lamp PCB Assembly Circuit Boards Heat Dissipation
Automotive PCBA Consumer Electronic PCBA LED PCBA Security PCBA

♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines

2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%

3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
