​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​
​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​
Specifications
Certification :
ISO, UL, IPC, Reach
Place of Origin :
China
MOQ :
1
Price :
Contact us
Payment Terms :
T/T
Delivery Time :
5-30 days
Layer :
2-36 Layer
Material :
FR4
Board Thickness :
0.2-10mm
Surface Finish :
Immersion Gold
Pin Space :
0.25mm
Application :
Automotive Electronic
Description

High-Precision BGA Assembly Services with IPC-A-610 Certified​

♦ What Is BGA Assembly Service?

BGA Assembly Services​​ refer to specialized ​​PCB (Printed Circuit Board) assembly processes​​ designed to handle ​​Ball Grid Array (BGA) components​​, a type of advanced surface-mount packaging used in modern electronics.

♦ Key Features of BGA Assembly Services:​​​​

  1. ​​BGA Soldering​​

    • Uses ​​reflow soldering​​ to attach BGA components, where solder balls melt to form electrical connections.
    • Requires ​​precise temperature control​​ to prevent defects like voids or cold joints.

  2. ​​High-Density PCB Support​​

    • BGAs allow for ​​more connections in a smaller space​​, making them ideal for compact, high-performance devices (e.g., CPUs, GPUs, smartphones, IoT devices).

  3. ​​Advanced Inspection & Testing​​

    • ​​X-ray inspection (AXI)​​ checks for hidden solder defects (e.g., bridging, misalignment).
    • ​​Electrical testing​​ ensures functionality.

  4. ​​BGA Rework & Repair​​

    • ​​Reballing​​: Replacing damaged solder balls.
    • ​​Replacement​​: Removing and replacing faulty BGAs without damaging the PCB.

  5. ​​Materials & Techniques​​

    • ​​Underfill epoxy​​ (for mechanical stability in high-stress environments).
    • ​​Controlled atmosphere soldering​​ (to reduce oxidation).

​​♦ Why Are BGA Assembly Services Important?​

    • ​​Complexity​​: BGAs are harder to solder than traditional components (e.g., QFP, SOIC) due to hidden solder joints.
    • ​​Reliability​​: Proper assembly prevents failures in critical applications (medical, aerospace, automotive).
    • ​​Miniaturization​​: Supports high-density designs in modern electronics.

DQS Electronic Group is one of the leading EMS company in China, we provide PCB design, PCB manufacturing, PCB assembly service and testing. Welcome send us your Gerber file to get free quotation. Our email: sales@dqspcba.com

♦ Technical Parameters

PCB Assembly Capability

Item

Normal

Special

SMT

Assembly

PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm, W≥3mm

L＜2mm

Maximum

L≤800mm, W≤460mm

L ＞ 1200mm, W＞500mm

Thickness( T)

Thinnest

0.2mm

T＜0.1mm

Thickest

4 mm

T＞4.5mm

SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm＜T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch＜0.4mm

CSP/ BGA

Min ball space

0.5mm

0.3mm≤Pitch＜0.5mm

DIP

Assembly

PCB specification

Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L＜50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mm, W≥500mm

Thickness( T)

Thinnest

0.8mm

T＜0.8mm

Thickest

3.5mm

T＞2mm

♦ Application Fields

​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​ ​​High Precision BGA Assembly Electronic Prototype Board IPC-A-610 Certified​
Automotive PCBA Consumer Electronic PCBA LED PCBA Security PCBA

♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines

2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%

3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
