Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Specifications
Brand Name :
KCO, Kocent Optec Limited
Model Number :
KCO-ODP-16B
Certification :
ISO9001
Place of Origin :
Guangdong, China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
Western Union,T/T,L/C
Supply Ability :
20,000 pcs/ month
Delivery Time :
7~14 days after get payment
Packaging Details :
carton box, wooden pallet
Material :
ABS+PC
Insertion loss :
0.15dB
Return loss :
55dB
Connector :
SC, ST, LC, FC, E2000, etc
Application :
outdoor
Capacity :
16 fibers fo
Description
Outdoor Fiber Optic Terminal Box with UV Protection and Anti-Aging Material
KCO-ODP-16B 16-port outdoor fiber optic splitter distribution box is a waterproof plastic optic distribution box designed for wall mounting or pole mounting with IP67 protection. This terminal box is mounted to interior and exterior walls of buildings or poles to distribute and connect optical cables for subscriber distribution in FTTH networks.
Key Features
  • Water-proof design with IP-67 Protection level
  • Integrated with splice cassette and cable management tools
  • Manage large quantities of fiber with high packing density
  • Easy to maintain and extend capacity
  • Fiber bend radius control more than 40mm
  • Suitable for fusion splice, mechanical splice, or fast connector
  • Capacity of fiber up to 16 ports
  • Various adaptors available (SC/LC/FC/ST/E2000)
  • 1×8 or 1×16 PLC Splitter can be installed as an option
  • Efficient cable management system
  • UV protection and anti-aging material
  • Burglar-proof padlock for security
Technical Specifications
Item KCO-ODP-16B Cladding diameter(μm) 125.0±1
Product Type 16 core distribution box Adaptor type SC/LC/FC/ST/E2000
Protection Class IP67 Wavelength 1260-1650nm
Shock-resistance 750N Card Splitter Type 1x16 / 2x16
Type Waterproof outdoor Application FTTH FTTB FTTX
Box Material PC/SMC/ABS Operating temperature -40℃ ~ +60℃
Product Gallery
Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material Outdoor Fiber Optic Terminal Box UV Protection And Anti - Aging Material
Performance Specifications
  • Vibration, pressure and pulling protection, endures bad situations like quake, knocking, pulling and distortion
  • Waterproof design with creative complete seal plastic band with re-opening style
  • Anti-UV, ultra violet resistant and rainfall resistant
  • Fire protection rated for -40°C to +80°C
  • Aging protection with good stability for heat, heating energy radiation, air and ozone
  • Can accommodate 1x4, 1x8, 1x16 & 1x32 PLC splitters
  • Up to 24 FTTH drops capacity
  • Wall and pole mountable design
  • 1~3 inlet ports, 8~24 outlet ports
Applications
  • FTTX Systems
  • Telecommunication Networks
  • PON Networks
  • Data communications Networks
  • Fiber Optic Termination
  • Local Area Networks
  • CATV Networks
Operation Conditions
  • Temperature: -40℃ to +60℃
  • Humidity: 93% at 40℃
  • Air Pressure: 62kPa to 101kPa
Packing Information
Model N.W (kg/pcs) Dimension of outer carton (mm) G.W of outer Carton (kg/carton) No of Products (pcs/carton)
KCO-ODP-16B 2 550×360×620 18 10
Package Includes
  • Terminal box, 1 unit
  • Keys for lock, 2 keys
  • Wall mount installation accessories, 1 set
