Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet
Specifications
Brand Name :
D.K.HISTRION
Model Number :
JL3015
Certification :
CE,ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
15000-300000USD
Payment Terms :
T/T
Supply Ability :
20SETS/MONTH
Delivery Time :
60 days
Packaging Details :
suitable for long distance transport
Product Name :
Laser Cutting Machine
Automation Level :
Fully Automatic
Control System :
CNC Controller with Touchscreen
Origin :
China
Warranty time :
One year
Function :
Coil sheet cutting
Description
Fed Roll Coil Laser Cutting Machine
Key Advantages
  • Fast cutting speed with high precision and excellent cutting quality
  • Narrow cuts with smooth surfaces that don't damage the sheet material
  • Versatile operation regardless of workpiece shape or material hardness
  • Cost-effective solution that saves on mold investment and conserves materials
  • Easy to operate with safe, reliable performance and enhanced flexibility
  • Modular design allows individual use of components or integration with other machinery
Production Line Functionality
  • 20T material loading capacity - 6 times more efficient than standard 3T feeding equipment
  • Advanced stress relief system ensures flatter sheet material for superior cutting results
  • Ultra-precision transmission system with ±0.5mm accuracy
  • Fully automated process from feeding to unloading with zero coil material waste
  • Breaks through conventional laser cutting length limitations
Technical Specifications
Model JL2515/3015/4025/6015
Power 1000W, 2000W, 3000W (optional)
Dimensions 15980 * 4850 * 2650 mm
Coil Sheet Thickness 0.5-3 mm
Roll Width 200-1600 mm
Coil Material Weight 20T
Feeding Speed Max 22 m/min
X/Y/Z-axis Cutting Travel 4050 mm / 1525 mm / 80 mm
X/Y-axis Cutting Repeatability ±0.03 mm
X/Y-axis Max Positioning Speed 140 m/min
Product Images
Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet

Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet

Fully Automatic CNC Laser Cutting Machine 20T Loading Capacity for Coil Sheet

Frequently Asked Questions
How can I choose the most suitable machine?
Please provide details about your intended applications (engraving, cutting, marking), primary materials, maximum cutting thickness requirements, and desired working area dimensions.
What is the delivery timeline?
Standard machines are delivered within 30-40 days. Customizable machines require 45-60 days for delivery.
Is technical support available after installation?
Yes, our comprehensive after-sales service team provides technical support, including machine installation assistance and free operator training.
What is your warranty policy for parts?
During the warranty period, we repair or replace defective parts at no cost (excluding consumable parts and damage caused by improper operation).
