Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel
Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel
Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel
Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel
Specifications
Brand Name :
D.K.HISTRON
Model Number :
HC3015/3000W
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
12000-300000USD
Payment Terms :
T/T
Supply Ability :
25 sets/month
Delivery Time :
60 DAYS
Packaging Details :
suitable for long distance transport
Product Name :
Laser cutting machine
Control System :
CNC Controller with CAD/CAM software compatibility
Dimensions :
4000mm x 2000mm x 1500mm
Laser Power :
500W - 6000W
Working Area :
1000mm x 2000mm (customizable)
Cutting Thickness :
0.5mm - 30mm (depending on material and power)
Cutting Method :
Laser Cutting
Cooling System :
Water Cooling System
Positioning Accuracy :
±0.03 mm
Repeat Positioning Accuracy :
±0.02 mm
Material Compatibility :
Metal Plates (Steel, Stainless Steel, Aluminum, etc.)
Laser Type :
Fiber Laser / CO2 Laser
Description
Laser Cutting Machine for Sheet Metal China Laser Cutting Machine Cutter Machine Iron
High-Performance Single Table CNC Fiber Laser Cutting Machine

This industrial-grade CNC fiber laser cutting machine delivers exceptional precision and speed for metal fabrication applications. Engineered with advanced servo motor technology and professional display software, it provides flexible processing options with simple, convenient operation.

Introdution:

Workbench:the carbon fiber laser cutting machine workbench using top and intensive type,with the design of elevating high speed double work table,which can prepare for the next feeding during working,it improve the working efficiency .

Slagging system: lower bed is equipped with partition to collect ,which can gather the waste and the small component in the process of production.

Dust removal system:the laser cutting machine workbench uses partition vacuuming design, equipped with external oil extraction, which is used for removing dust flue gas and so on in the process of production.

Transmission system: the small fiber laser cutting machine transmission system uses German ATLAMTA pinion and rack for accurate transmission and Japan servo motor

control system:The 500w fiber laser cutting machine operating system can use editing software and secondary development tool to customize the special interface and function,it is easy for customers to create their own man-machine interface.

Material Compatibility

Suitable for cutting stainless steel, carbon steel, alloy steel, silicon steel, galvanized steel sheet, nickel-titanium alloy, chromium-nickel-iron alloy, titanium alloy, and various other metal materials.

Technical Specifications
Mode HC3015 HC4020 HC6025
Working Area 3000*1500mm 4000*2000mm 6000*2500mm
Repeat Repositioning Accuracy +0.03mm
Accuracy of Positioning +0.02mm
X, Y Max linkage Speed 145m/min
Laser Power 1000W / 1500W / 2000W / 3000W / 4000W / 6000W / 12000W
Laser Source MAX / Raycus / IPG
Maximum acceleration 2G
Upgrade Tube cutting / Exchange platform / Enclosed protection
Product Gallery
Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel

Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel

Sheet Metal CNC Laser Cutting Machine For Stainless Steel / Carbon Steel

Frequently Asked Questions
Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis/Conformance, Insurance, Origin, and other export documents where required.
Are you manufacturer or trading company?
D.K.HISTRON is a professional manufacturer of CNC sheet metal fabrication machinery and laser machines.
What is the product warranty?
We warrant our materials and workmanship. Our commitment is to your satisfaction with our products. In warranty or not, it is our company culture to address and resolve all customer issues to everyone's satisfaction.
How about the shipping fees?
The shipping cost depends on the way you choose to get the goods.
