Specifications
Brand Name :
D.K.HISTRON
Model Number :
HC-2500
Certification :
CE,ISO9001
Place of Origin :
CHINA
MOQ :
1SET
Price :
12000-200000USD
Payment Terms :
T/T
Supply Ability :
20sets/month
Delivery Time :
60days
Packaging Details :
polyfilm and wooden
Productname :
File Cabinet Panel Bender Machine
Type :
Mertal Bending Machine
Speed :
Adjustable bending speed
Controlsystem :
CNC (Computer Numerical Control)
Precision :
±0.1mm
Safetyfeatures :
Emergency stop
Automationlevel :
Fully automated
Powersupply :
Electric
Warranty :
1 Year
Voltage :
380V,380V/220V Optional,Customized,or as the customer's requirement,380V or 220V/60HZ /3P
Condition :
New
Cnc or not :
CNC,Normal
Description
CNC Panel Bender with ±0.1mm Precision and 13-Axis Synchronized Coordination Featuring Automatic Lubrication System
Advanced CNC panel bender and sheet shaping machine designed for precision metal fabrication with automated operation and high-efficiency performance.
Product Advantages
  • High-strength Q235B/Q335B welded frame ensures stability under high-tonnage impact
  • Double L-shaped guide positioning with front material pushing improves forming accuracy
  • Automatic lubrication system with oil shortage alarm reduces maintenance frequency
  • Quick-clamp quick-release tool change with reinforced C-axis rotation improves changeover efficiency
  • Self-developed control system ensures precision and reliability
Product Functions
  • Automatic feeding positioning: Pressure arm clamping with precise feeding
  • Multi-axis linkage control: 13-axis synchronized coordination
  • Graphical error detection programming: Input dimensions, auto-programming with result preview
  • Cloud operation interface: Real-time equipment status monitoring
  • Automated production line interface: Connectable to loading/unloading robots
  • Partial load visualization: Real-time force display for timely adjustment
  • Self-diagnosis function: Reduces maintenance downtime
Operation Instructions
Check lubricant level before startup. Power on and enter the control system main interface. Input workpiece dimensions in the graphic programming interface. The system automatically generates bending paths and displays forming preview. Confirm correctness and start automatic processing. Monitor partial load display during processing. Remove workpiece and inspect quality after completion.
Technical Parameters
Model HC-2500 HC-2500P
Feeding structure Pressure arm type Pressure arm type
Minimum internal dimensions for quadrilateral forming 180mmx280mm 180mmx280mm
Bending height 170mm(customizable) 170mm(customizable)
Average power About 2.9KW About 3.5KW
User operating environment Operation system above Win7 Operation system above Win7
Maximum bending thickness Cold plate 1.5mm Cold plate 2.0mm
304 stainlesss steel 1.0mm 304 stainlesss steel 1.5mm
Number of axles 13 13
Control System
The bending center control system employs a top-level computer numerical control (CNC) system integrated with motion control cards. The CNC system features an intuitive human-machine interface and supports graphical programming. With exceptional position calculation capabilities, it significantly enhances production efficiency and precision in automated manufacturing. The motion control cards support 24-axis operation, with an expandable capacity up to 64 axes, and utilize EtherCAT bus control for high-precision motion control.
Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination
Operation Interface
The interface is simple, easy to learn, with excellent human-computer interaction designed for efficient operation.
Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination
Industrial Applications
Widely used in file cabinetry, electric cabinet, aluminum veneer wall industry, stainless steel kitchenware industry, refrigeration equipment industry, chassis and cabinet industry, laboratory construction industry, metal door industry and related metal fabrication sectors.
Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination

Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination

Automatic Lubrication System CNC Panel Bender 13 Axis Synchronized Coordination

Shipping & Delivery
Delivery time: 60 working days after deposit confirmation. Transportation methods: Sea freight or land transport available, handled by professional freight companies. Full function testing conducted before shipment. Export documents include commercial invoice, packing list, certificate of origin, etc.
Frequently Asked Questions
Can you arrange samples for me?
Of course, we provide free samples according to customer requirements.
What is the warranty period for the machine?
The warranty period for the machine is one year. Lifetime maintenance and upgrade services are provided after the warranty period.
Are all the machines standard?
No, customization is available. We can manufacture non-standard machines according to customer requirements.
