85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
Specifications
Brand Name :
FTD
Model Number :
FIP-910SIP
Certification :
CE
Place of Origin :
CHINA
MOQ :
10
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500PCS Per Month
Delivery Time :
10-15 work days
Packaging Details :
Carton
Network I/F :
10/100Mbps
Protocol :
SIP, TCP/IP, UDP, ICMP & IGMP (Group Broadcast)
Audio Format :
MP3/MP2
Sampling Rate :
8K~48K
Bit Rate :
8K~512Kbps
Sensitivity :
92dB/1W/1M
Description
SIP IP Ceiling Speaker 10W
Product Description

The IP Ceiling Speaker is the latest in IP technology. This Power over Ethernet (Compatible with both IEEE 802.3af & IEEE 802.3at) VoIP mass notification device has network-controlled speaker volume, scheduled program broadcast, priority-based multicast streaming, group definition, working status supervision, remote online technical support and trouble shoot. The speaker is capable of broadcasting audio through multicast.

The IP powered ceiling speaker enable to be built up an IP based sound system through a single CAT5 or CAT6 wire. The single CAT5 cable is used for control data, signal data and power supply, by this way, the layout cost will be much decreased without any consideration of AC nor DC power supply.

The IP powered ceiling speaker is compatible with universal switch, thus the speaker works with existing LAN/WAN & internet network and fiber-optical cable, no need dedicated network to be built-up. So it is very useful for office, hotel, school, bank, factory & shopping mall where network is already there. External DC12V connector is also equipped in this POE speaker for standby power supply use.

The IP ceiling speaker is designed with 6” full range ceiling speaker with 10 W class-D amplifier.

There is one Emergency Call Button input to connect with one external emergency button, by pressing the button, the remote call station FIP-900TM will be reminded by its ID or pre-set room number with ring bell. The remote call station FIP-900RM enable to make announcement to this room by answer this call. There is emergency light output once the emergency button is pressed.

85dB S/ N Ratio SIP IP Ceiling Speaker 10W
Product Features

With an integration of the network audio decoding and digital amplifier and speakers and a installation of wall-mounted design;
With a built-in hi-fi speakers and stereo Class-D power amplifiers(10 watts (8Ω)
Supportive of SIP protocol, with the function of adjusting speaker output volume remotely on server;
With a high-speed dual-core (ARM + DSP) chip of industrial grade; start time≤1 s
With a standard RJ45 interface supportive of crossing network segment and router, accessible to the system if the Ethernet is available;

Specification

Model FIP-910SIP
Description IP Based Ceiling Speaker
Power Output 10Watts RMS & 15W Watts Max (1KHz@-3dB)
Built-in Amplifier 10W Class D amplifier
Network I/F 10/100Mbps
Protocol SIP, TCP/IP, UDP, ICMP & IGMP (Group Broadcast)
Audio Format MP3/MP2
Audio Quality 16digit stereo CD level
Sampling Rate 8K~48K
Bit Rate 8K~512Kbps
Sensitivity 92dB/1W/1M
S/N Ratio ≧85dB
THD ≦0.1%
Frequency Response 100-18KHz(±3dB)
Connector One RJ45 port for existing LAN/WAN & internet, 1DC input and 1 contact in and contact out.
Power Input POE 802.3af or POE 802.3at & DC 12V
Operation Temp -30 to 55℃
Dimension 200(Diameter)×100(Depth)mm
Cutout Size 175mm
Weight 1.2kg

Certifications&Exhibition
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
85dB S/ N Ratio SIP IP Ceiling Speaker 10W
Company Introduction

Guangzhou FTD Audio Limited is a leading manufacturer of Public Address System and Conference System in China, We are focus on R&D and our Professional R&D team already 15 years' experience on Audio field.

85dB S/ N Ratio SIP IP Ceiling Speaker 10W

Our Services & Strength

1.One year warranty after sales. if any problem happened under warranty , you can return to us and fix it.

2.Accept OEM and ODM order for our customers.

3. Stable quality with good quality control, quality is our life.

4. 7*24 hours quick response for technology support.

5. Various PA system product for one shop purchase.

6. System solution designed can be offered base on requirement.

7. Reasonable price for a win win business .
