AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
Specifications
Brand Name :
FTD
Model Number :
FIP-900FA
Certification :
CE
Place of Origin :
CHINA
MOQ :
10
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500PCS Per Month
Delivery Time :
10-15 work days
Packaging Details :
Carton
Weight :
2.5kg
Color :
Black
Power Consumption :
15W
Audio Sampling :
8KHz-48KHz, 16 bits
Frequency Response :
20Hz-20KHz
S/N Ratio :
≥90dB
Description
IP System Audio IP Network Fire Alarm Panel (32 Zone)
Product Description
Product Name
IP Network Fire alarm Panel (32 zone)
Material
Metal
Package
Carton
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier

  • Product performance description

32 Zone IP Fire Alarm Panel, interface of fire alarm system with public address system, automatically trigger the voice alarm system or pre-recorded voice message broadcasting after receiving trigger, 19" rack mount design, with IP addressable, AC220V power supply. 1U height
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
Details Images
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
Product Features
  • Interface between fire alarm and IP network audio system.
  • Automatically broadcast the pre-recorded voice alarm message once triggered by the closed contact from the fire alarm center.
  • Different zone trigger could be assigned with different voice messages.
  • The multiple pre-recorded voice messages are stored in the server or controller.
  • The fire alarm center send the fire alarm closed contact to this fire alarm panel, which will communicate with the server through the LAN RJ45 port, the server will give command to generate which pre-set voice message to be broadcasted to which speaker zone output.
  • One fire alarm panel support 32 speaker zones.
  • The fire alarm panel capable for both IP network PA and intercom system.
  • Each IP network audio system support more than 200 units working together for more than 6,400 speaker zones. The fire alarm panel could be built-up over existing LAN/WAN network, non-dedicated network is needed.
Specification

Model IP-900FA
Description IP Network Fire Alarm Panel
Power Supply AC220V or 240V, 50-60Hz
Power Consumption 15W
Network Protocol TCP, UDP, ARP, ICMP, IGMP
Network Speed 10/100Mbps
Audio Sampling 8KHz-48KHz, 16 bits
Transmission Rate 8Kbps to 320Kbps
S/N Ratio ≥90dB
Frequency Response 20Hz-20KHz
Data Delay <30 milliseconds
Connector One RJ45 port for LAN, 16 contact inputs and four contact outputs
Dimensions 483(W)×256(D)×44(H)mm
Weight 2.5kg

Certifications&Exhibition
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier
Company Introduction

Guangzhou FTD Audio Limited is a leading manufacturer of Public Address System and Conference System in China, We are focus on R&D and our Professional R&D team already 15 years' experience on Audio field. FTD audio will offer the professional products and service to each of partner and do a win win business with our partners!

AC220V TCP IP Network Alarm Panel 32 Zone 19in 1U Amplifier

Our Services & Strength

1.One year warranty after sales. if any problem happened under warranty , you can return to us and fix it.

2.Accept OEM and ODM order for our customers.

3. Stable quality with good quality control, quality is our life.

4. 7*24 hours quick response for technology support.

5. Various PA system product for one shop purchase.

6. System solution designed can be offered base on requirement.

7. Reasonable price for a win win business .
