Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Outdoor Optical Fiber Air Blown Micro Cable G652D G657A1 24 Core OM3
Specifications
Place of Origin :
CHINA
Brand Name :
SKYLYNN or OEM, ODM
Certification :
ISO, ROHS, CE
MOQ :
2KM
Packaging Details :
WOODEN DRUM
Delivery Time :
5-10 DAYS
Payment Terms :
T/T, L/C, WEST UNION
Supply Ability :
100,000 cores
Model NO. :
GCYTXTY/GCYFTY
Delivery :
EXW/FOB/CIF Etc.
Country of Origin :
GUA, CN
Description

Non-metallic Air Blown Micro Fiber Optic Cable

Description

Conventional center tube micro cable, 2 to 24 fibre 250 µm Micro Fiber Optic Cables with aramid strength members and single LSZH jacket. The cables consist of 2 to 24, 250 µm OM1, OM2, OM3, OM4 multimode or ITU-T G.652D, ITU-T G.657A1 or ITU-T G.657A2 single mode optical fibres in a 2.95 mm Low Smoke Zero Halogen (LSZH) inner jacket with aramid strength members.

Feature

  • Perfect cable structure with high fiber density
  • Accurate fiber length balance to ensure stable performance
  • No gel in cable core for water blocking
  • Sheath structure innovation to enhance blowing performance
  • Greater blowing distance
  • Fiber: G.G652D, G.657A1, G657A2 & multimode fiber
  • Special complex material loose tube, reduce the shrink of tube in cold temperature.
  • Accurate fiber length balance, stable mechanical and temperature performance.
  • Particular technique control, prevent sheath form crinkling during installation.
  • Structure Innovation in sheath, enhancing the blowing performance.

Optical Characteristics

G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm ≤3.0 dB/km ≤3.0 dB/km
(+20℃) @1300nm ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km ≤0.40 dB/km
@1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm ≥500 MHz·km ≥200 MHz·km
@1300nm ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm ≤1480nm


Technical Parameters

P/N Fiber count Nominal diameter Nominal weight Max tensile strength Temperature
(F) (mm) (kg/km) (N) (℃)
MICROC-2G652D-PE 2 4.0±0.1 10 120 -40 to +60
MICROC-4G652D-PE 4 4.0±0.1 10 120
MICROC-6G652D-PE 6 4.0±0.1 10 120
MICROC-8G652D-PE 8 4.0±0.1 10 120
MICROC-12G652D-PE 12 4.0±0.1 10 120
MICROC-24G652D-PE 24 4.5±0.1 14 150

BLOWING PERFORMANCE:

Fiber count (F) Blowing machine Suitable microduct (mm) Blowing pressure (bar) Blowing distance in 7/5.5 duct (m) Blowing distance in 10/8 duct (m)
2 to 12 PLUMETTAZ PR-196 7/5.5 or 10/8 15 1500 2500
14 to 24 or PR-140 7/5.5 or 10/8 1300 2200
