2 4 8 12 Cores Central Loose Tube Outdoor Fiber Optic Cable Armored Steel Belt
2 4 8 12 Cores Central Loose Tube Outdoor Fiber Optic Cable Armored Steel Belt
2 4 8 12 Cores Central Loose Tube Outdoor Fiber Optic Cable Armored Steel Belt
2 4 8 12 Cores Central Loose Tube Outdoor Fiber Optic Cable Armored Steel Belt
Specifications
Brand Name :
JIANGHONG or OEM
Model Number :
GYXTS
Certification :
Ce/ISO9001/Tlc
Place of Origin :
Sichuan, China
MOQ :
20,000 Meters
Price :
Can be negotiable
Supply Ability :
50000000m Per month
Delivery Time :
5-8Days
Packaging Details :
Fumigated Wooden Tray
Application :
Communication
Type :
Single-mode Fiber
Connection Structure :
Round wire
Core :
2-12cores
Fiber Model :
G652D
Loose tube Material :
PBT
Armored :
Steel Plastic Composite Belt
Sheath Material :
HDPE
Color :
Black
Length :
3km/Drum
Description

GYXTS Outdoor Fiber Optic Cable Single Mode 2 4 8 12 Cores

DESCRIPTION
GYXTS Outdoor Fiber Optic Cable is a single mode or multimode optical fiber set into a loose tube made of high-modulus plastic, filled with water-blocking compounds. 12 Phosphating steel wires armor windings outside the loose tube, and the water-blocking ointment between the twisted steel wire and the loose sleeve ensures the compact and longitudinal resistance, Finally, the longitudinal steel plastic composite belt and extrude the MDPE sheath into a cable

FEATURES
Excellent environment and mechanical performance
Gel-filled loose tube for better protection of fiber
12 twisted steel wires to ensure cable tensile strength and anti-gas bullets and rodent performance
Armored with anti-moist corrugated steel tape
Good water resistance performance

APPLICATIONS
Duct and Aerial
Telecommunication,power supply and radio&television departments
Self and Non-Self Supporting

PERFORMANCE

Type Max.Attenuation Tensile strength Crush resistance Min.Bending radius(Dynamic)
1310nm 1550nm Short term Long term Short term Long term
GYXTS 0.36dB/km 0.22dB/km 1500N 600N 1000N 300N 20D

Company profile

SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
