1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
Specifications
Brand Name :
X-media
Model Number :
P2.5
Certification :
CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Place of Origin :
Shenzhen,China
MOQ :
5sq.m
Price :
Negotiation
Payment Terms :
T/T, MoneyGram,Cash
Supply Ability :
5,000sq.m/month
Delivery Time :
8~10 working days
Packaging Details :
Flight case, wooden case and carton box and foam package
Product name :
Indoor full color Advertising LED Display
Cabinet material :
Die-casting Aluminum
Module size :
320mmx160mm
Screen dimension :
Customized design
Brightness :
>1000cd
Warranty :
5 years
Life span :
100000H
MTBF :
10000H
Description

Waterproof Dustproof Dampproof 4K GOB Indoor LED Screens High Definition

Product Advantage

1. The back of the module is plated with conformal coating to make sureGOB led screen is waterproof

2. GOB Led screen is damp-proof, it could effectively prevent over 85% dead lamp problems .

3. The front of the module is plated with a special material to protect LED from getting collision, so GOB led screen is anti-collision .

4. GOB Led screen could be used indoor or outdoor .

5. It looks like acrylic board covered the module effectively prevent Led lamp from getting impact .

6. GOB led screen can used for rental or fixed .

1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof

1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof

Pamameter

Module Parameters
Pixel Pitch 2.5mm
Pixel Configuration 1R1G1B
Density 160000 pixels/sqm
LED Lamp SMD2121
Module Size 320*160mm
Module Resolution (W)128Pixels * (H)64Pixels
Working Voltage DC5V
Scan Mode 1/32 Scan
Drive IC MBI 5124(Can be customized)
Port Type HUB75
Screen Parameters
Cabinet Size (W)640*(H)640mm
Cabinet Material Die-casting aluminum
Cabinet Weight 5.76KG
Cabinet Resolution 256*192 Pixels
Module Qty 8 pcs
Power Supply 200W
Working Voltage AC110-220V±10%
Max Power Consumption 600W/sqm
Ave Power Consumption 200W/sqm
Brightness 800 Nits
Refresh Rate 1920Hz/ 3840Hz
Frame Frequency 60Hz
Grey Scale 14 bit
Brightness Level 256 levels
Best View Distance 2.5M-50M
View Angle 120°(Horizontal); 120°(Vertical)
Protection Degree IP30
Working Temperature -20℃ ~ +60℃
Relative Humidity 10%-95%
Operation system WIN7/WIN8
Control Method Synchronous or Asynchronous
Control System NovaStar
Receiving Card MRV336
Control Distance 100M(Ethernet cable); 20KM(Optical fiber cable)
Input Signal Composite Video, S-video, DVI, HDMI, SDI, HD-SDI
Out-of-Control Pixel Rate ≤0.01%
Detailed Picture
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof
1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof

load testing for GOB led screen P2.5

Its not dance floor led screen.

Only to prove that our film coating technology is good enough to bear over 50kg weight .

1000cd Fine Pixel Pitch LED Display , GOB 4k LED Screen Indoor Dustproof

Our Service

1)Your inquiry related to our products or price will be replied in 24hrs

2)OEM&ODM,any your customized lightings we can help you to design and put into product

3)Distributoership are offered for your unique design and some our current models

4)Protection of your sales area,ideas of design and all your private information

5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
