P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
Specifications
Brand Name :
X-media
Model Number :
P1.667
Certification :
CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Place of Origin :
Shenzhen,China
MOQ :
5sq.m
Price :
Negotiation
Payment Terms :
T/T, MoneyGram,Cash
Supply Ability :
5,000sq.m/month
Delivery Time :
8~10 working days
Packaging Details :
Flight case, wooden case and carton box and foam package
Product name :
Indoor Fine Pixel Advertising LED Display
Cabinet material :
Die-casting Aluminum
Module size :
200mmX150mm
Screen dimension :
Customized design
Brightness :
>1000cd
Warranty :
5 years
Life span :
100000H
MTBF :
10000H
Description

GOB LED Wall Screen P1.667 High Resolution with Die-casting Aluminum

♦ The Features of GOB LED Display


1) waterproof
2) dustproof
3) moisture proof
4) anti-collision
5) anti-UV
6)avoid LEDs fall off

P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor

GOB 4:3 Design and Good Uniformity

4:3 design:Cabinet's 4:3 resolution is specialized for command center. Perfect replacement for LCD display.
Die cast aluminum cabinet, guarantee you a flat and seamless screen.
Good uniformity. Dot-to-dot correction technology provide you pure image with great gradation.
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
Excellent Display Effect
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor

Ultra wide angle of view


Ultra wide angle of view,from any perspective images are clear natural,to experience the great subversive viewing experience

P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor

Specifications :

indoor SMDP1.667
Resolution/mm 1.667mm
Pixel configuration 1R1G1B
Pixel density/pixels/m² 359856/m²
Module resolution 120x90
Module size/mm 200x150MM
View distance 2-80m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/43 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Function and Technology Character:

1. Support multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on

2. The screen can get singal of camera, video, VCD, DVD, LD, TV and so on.

3. Brightness, contrast, saturation can be adjusted automatically by itself and manual.

4. Clear picture without flicker and distortion.

5. Show everything with your PC synchronously.

6. Super correcting technology for distortion.

7. One interface for sound signal and two ports for video signal at least.

8. Connected and controlled by PC via Lan and remote control.

9. Multiform language are available,such as English, French, Germany, Spanish, Russian and so o

♦ Our advantages

Professional Manufacturer of led display

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 8-10working days

8. Excellent R&D team,factory Price and assure you quality goods.

Trade Terms:
1. Payment: T/T, 40% deposits before production, 60% balance to be paid before shippment.
2. Freight charges are quoted under your requests
3. Shipping port: Xiamen, China
4. Warranty time: 5 years.If there is no manmade problems,we will repair for you freely

Installation procedure

P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
Packing and shipping
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
P1.667 High Resolution LED Display , anti UV LED Wall Screen Display Indoor
