1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display
Specifications
Brand Name :
X-media
Model Number :
P1.875
Certification :
CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Place of Origin :
Shenzhen,China
MOQ :
5sq.m
Price :
Negotiation
Payment Terms :
T/T, MoneyGram,Cash
Supply Ability :
5,000sq.m/month
Delivery Time :
8~10 working days
Packaging Details :
Flight case, wooden case and carton box and foam package
Product name :
Fine pitch LED TV display
Cabinet material :
Die-casting Aluminum
Module size :
240mmx240mm
Screen dimension :
Customized design
Brightness :
>1000cd
Warranty :
5 years
Life span :
100000H
MTBF :
10000H
Description

Led Video Wall Indoor Full Color LED Display High Refresh Rate over 3840hz P1.875

Features


1, The led display screen have optional data interface depend on customers' requirements like DVI, VGA,

RGB, Pr Pb HDMI etc.
2, Our led display is PC connected and synchronously show all kinds of word, text, graph, picture, flash,

existing video, real time video, 2-dimention cartoon, and 3-dimention cartoon supported by your personal

computer.
3, Our led display have free control system software with on-line update and 12 kind of language including

English, French, Spanish, Polish, Italian, Portuguese, Russian and Korean.

4, Easy installation without any steel structure, wall-mounted installation or hanging installation

5, All parts front access to save installation space, more convenient for maintenance and installation

Indoor Full Color Led Display Product Specification

Item Technical parameter

Panel

 Dimension (W)240mm*120mm(H)
Pixel pitch 1.875mm
Pixel Density 284444dots/m2
Pixel configuration 1R1G1B
Led Lamp Kinglight
LED specification SMD 1010
Led Chip Epistar
Pixel resolution (W)64*64(H)
Panel weight 0.5KG

Cabinet&Bracket

 Bracket size 400mm*300mm*85mm
Weight for bracket 9KG/M2
Best viewing distance 120/90
Best viewing angle 6-20M
Working temperature -20-+65
Panel power supply 5V40A
Screen power supply AC110V—AC250V
Max power 800W/M2
Average power 350W/M2

Technical Parameter

 Driving device Constant current drive
Drive type 1/32 Scanning
Refresh frequency 3840HZ/S
Brightness 1000cd/M2
Life span 100000Hours
Communication distance

<100M

Indoor Full Color Led Display Production process

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display

Indoor Full Color Led Display Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

1.875mm Fine Pixel Pitch LED Display 240mmx240mm Small Pitch LED Display

FAQ

What kind of payment terms you can accept ?

We can accept T/T and .

What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the

quality of our products continuity.

What is your delivery time ?

Within 8-10 days according to your area and quantity.

Is your LED display competitive ?

Yes,we are led display manufacturer for more than 12 years.Mass and professional production

ensure our led display’s competitiveness.

Our advantages

Professional Manufacturer of led display

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 8-10 working days

8. Excellent R&D team,factory Price and assure you quality goods.
