4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication
Specifications
Brand Name :
X-media
Model Number :
P1.538
Certification :
CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Place of Origin :
Shenzhen,China
MOQ :
5sq.m
Price :
Negotiation
Payment Terms :
T/T, MoneyGram,Cash
Supply Ability :
5,000sq.m/month
Delivery Time :
8~10 working days
Packaging Details :
Flight case, wooden case and carton box and foam package
Product name :
Fine pitch LED display
Cabinet material :
Die-casting Aluminum
Module size :
320mmx160mm
Screen dimension :
Customized design
Brightness :
>1000cd
Warranty :
5 years
Life span :
100000H
MTBF :
10000H
Description

Indoor Nation star Leds P1.538 LED Display 4K 8K Pixel Density for TV Indication

Advantage

1. 4:3 golden ratio 640x480 Die-casting Aluminum LED Panels, 80mm thickness, 7.6kg/pcs panel.

2. high gray scale, 5000:1 contrast ratio,16 bit gray level, 3840Hz refresh rate
3. seamless tiled display, <0.01mm.
4. wide color gamut, good color uniformity, less glare and less shadow
5. Natural heat dissipation, ultra silence
6. die-casting aluminum, CNC fine finishing,good flatness
7. with anti-slip handles, and high quality fast locks
8. wireless connection,double backup design, with double control cards.
9. support both rear and front service

Specifications:

SMD P1.538
Resolution/mm 1.538
Pixel configuration 1R1G1B
Pixel density/pixels/m² 422500dots/square meter
Module resolution 208x104
Module size/mm 320x160mm
View distance 2-30m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 1000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/52 SCANNING
Frame rate 60Hz
Refresh frequency 3840Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Product Details

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

Ultra HD Visual Feast

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

4K is not the end!

Ultra-high resolution brings delicate display effect and and it is a perfect embodiment of new generation of UHD LED Display technology.

Small pixel pitch easy reach FHD(1080P) even 4K(2160P) or more.

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

High contrast, High refresh rate

Top quality black body SMD lamps and top level driver IC to provide the high refresh rate (≥2000Hz), high contrast ratio (3000:1), high grayscale (16bit), Display the smooth, colorful, clear, perfect image.

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

Wide viewing angel

High quality SMD1010 black body lamps provide 160°/160° (horizontal / vertical) viewing angel make sure you can watch it in any directions.

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

Extreme flatness

Cabinet is made by high precision die-cast aluminum alloy also first-class CNC machines to guarantee the screen is seamless and flatness like a mirror.

4K 8k Fine Pixel Pitch LED Display P1.538mm for TV Indication

Trade Terms
Payment terms:

30% deposit before production, 70% balance before shipping

-T/T:

-Paypal

-

-Escrow
Packing:

-Standard Export Carton with fully Polyfoam or Pearl Wool

-Flight case;

-Anti-shaking wooden case
Shipping:

LED module: 3 to 5 working days upon receiving deposit payment

LED display: 8 to 10 working days upon receiving deposit payment
After-Sales-Service:

-Lifetime with professional engineer support for free.
-Within 5 year, supply spare parts for free if the machine

has quality problem

Our Service

1. Warranty
1) We provide warranty of all components for 5 full years. During this time, we will replace or repair our goods for free if there is something wrong with them.
2) We will provide maintenance for a lifetime and charge for the raw materials only.
2. Technology Training
1) We provide the technology training for free, which contains the operation training and maintenance
2) training in the factory.
3) We will send our engineers to your country by negotiation.
3. Maintenance and Consultation
1) We provide full maintenance for a lifetime and charge for the raw materials only.
2) We also provide lifetime consultation by E-mail, Skype, WhatsApp or other ways for free.
4. Documents and Certification
1) We provide the operation manual, software, test report and so on.
2) We can also provide all kinds of certification such as CE, LVD, RoHS and so on.
5. CAD Drawing and Fixing
1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional Service
1) We provide you the forwarding information, and some other information such as flight box, structure
