Specifications
Brand Name :
SINOHONE
Model Number :
Duplex Figure 8 Indoor Cable
Certification :
CPR FCC CE RoHS ISO9001
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Duplex Figure 8 Indoor Cable
Strength Member :
Aramid Yarn
Operating Temperature :
-40°C~+60°C
Storage Temperature :
-5°C~+50°C
Transport Temperature :
-5°C~+50°C
Installation Temperature :
-5°C~+50°C
Distance :
Customize
Description

Duplex Figure 8 Indoor Fiber Optic Cable FTTH Indoor Cable Armored

Duplex figure 8 indoor cable

A duplex communication system is a point-to-point system composed of two or more connected parties or devices that can communicate with one another in both directions. Duplex systems are employed in many communications networks, either to allow for simultaneous communication in both directions between two connected parties or to provide a reverse path for the monitoring and remote adjustment of equipment in the field.

Characteristics:

  • Tight buffer fiber, be striped easily and excellent flame retardant;
  • Aramid yarn makes the optical fiber cable have excellent performance of flame and tensile strength resistance;
  • Easy installation. Separated easily and used as single unit;
  • Material of outer sheath shall be corrosion resistant, water-blocking and flame retardant and environment friendly etc.
  • Not be influenced by electromagnetism due to all dielectric structural design.

Item Duplex Figure 8 Indoor Cable
Standards YD/T1258.3
IEC60794-2-10/11
Applications

Access network

Fiber to the Home(FTTH)
Strength Member Aramid Yarn
Temperature Operating temperature: -40°C~+60°C
Storage, transportation and installation temperature: -5°C~+50°C

Technical Parameters

Nominal diameter (mm) Nominal weight (kg/km) Permitted Tensile(N) Permitted Crush(N) Bending Radius(mm)
Long term Short term Long term Short term Static Dynamic
1.6*3.3 5 100 200 100 500 10D 20D
1.8*3.7 6 100 200 100 500 10D 20D
2.0*4.1 8 100 200 100 500 10D 20D
2.4*4.9 11 100 200 100 500 10D 20D
2.5*5.1 12 100 200 100 500 10D 20D
2.8*5.7 14 100 200 100 500 10D 20D
3.0*6.1 15 100 200 100 500 10D 20D

Note:

  1. The structural dimensions and materials used can be designed according to the demands of the customers.
