Specifications
Place of Origin :
Sichuan, China (Mainland)
Brand Name :
Sinohone
Model Number :
HY-512I, HY-512I
Supply Ability :
50000 Piece/Pieces per Month
Packaging Details :
Poe Industrial Fiber Optic Media Converter 1 pc in a box
MOQ :
100 - 499 Pieces
Price :
$38.00~58 per piece
Certification :
CE FCC CPR ISO9001 RoHS
Key words :
Poe Industrial Switch Converter
Function :
POE, SNMP, VLAN support, WEB smart
Transmission Rate :
10/100/Mbps
Communication Mode :
Full-Duplex & Half-Duplex
Ports :
3 Ports with 2 POE+1 Uplink SFP port
Operating temperature :
Industrial grade: (-40 ° C~ 80 ° C)
Storage temperature :
-40°C~85°C
Certificate :
ROHS / UL /CE / CPR / ISO9001
OEM/ODM :
Available
Delivery Port :
Shanghai
Description

10/100base-T To 100base-X Media Converter SC Industrial POE Media Converters

Product Description
Item 10/100 Poe Industrial Fiber Optic Media Converter
Number of interfaces SFP ports (or specify other optical port forms):1
Electrical ports (POE power supply):2
Exchange capacity 53G
Mpps 10/100Mbps RJ45 Ports
POE power supply Support
Power Consumption Max.3.5W
Levels of protection IP40
Model No. HY-512I
Exchange Capacity 53G
Power and power supply No fan, low power consumption, the total power consumption of the equipment is less than 10/15W
Industrial grade supports dc or ac power (dc parameters: default -48v: -36v ~ -72v, ac parameters: default 220V: 100V ~ 260V)
Other features Port convergence /LACP supported, support 1:1 port protection
Support interport protection based on the LACP protocol, linear protection based on the G.8031 protocol and ring network protection based on the G.8032 protocol
Support port redirection and port mirror function, support port-based failover capabilities
Support MSTP/RSTP protocol
Support fiber breakage alarm;Support power failure warning of Dying Gasp remote device
Support equipment online upgrade
Support storm suppression and port speed limit, speed limit granules up to 64K
Support SLA, Link performance tests such as link delay, jitter, packet loss and throughput can be implemented
Support port-based, 802.1p, DSCP, TOS, MAC address, VLAN ID, Ethernet Type
Operating Temperature Industrial grade: (-40 ° C~ 85 ° C)
Storage temperature -40°C~80°C

Characteristics

  1. Industrial design, 2x 10/100M Ethernet RJ45 ports with AutoUplink™ and 1x 100M SC optical port
  2. Supports IEEE802.3x flow control for Full-duplex Mode and back pressure for Half-duplex Mode
  3. RJ-45 port supports Auto MDI/MDI-X
  4. Automatic MAC address learning and aging
  5. Auto-Negotiation for Full-duplex Mode and Half-duplex Mode
  6. Plug and play, with LED indicators for monitoring power/link/activity, easy to use.
  7. Provides DIN35 rail-type installation method
  8. Electromagnetic compatibility of up to 4 grade standard
  9. IP40 protection class
  10. Superior performance, successfully used in industrial field
  11. Default PoE power supply type is end-span, mid-span optional
  12. Power ports supports both IEEE802.3af and IEEE802.3at standard PoE power supply.
