sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft
Specifications
Brand Name :
HANJIU
Model Number :
BMK2-315
Certification :
CE
Place of Origin :
China
MOQ :
100 Pieces
Price :
90 USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,Payple
Supply Ability :
10000 pieces per year
Delivery Time :
35 - 45 work days
Packaging Details :
1 pc/ inner carton, 2 pcs/ outer carton, 31x31x17cm, transport with wooden pallet, 650 pcs/ 20GP, 1300 pcs/ 40GP
Type :
Low speed high torque motor
Material :
Cast iron
Displacement :
400ml/r
Flange :
4bolts wheel Flange
Port size :
SAE Ports
Drain line :
7/16-20UNF
Speed :
246 - 365 rpm
Torque :
765 - 885 nm
Description

sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft


Hanjiu technology produce BMK2 series hydraulic disc motors, matching Eaton Charlynn 2000 Motors

which are used on sugarcane harvesters, the same specification ,same performance, but in a cost effective,

to cut your costs down, optimize your supply chain


Quick review:

Model No.:CB11480557


type BMK2 MOTOR, eaton 2000 series motor,2k motor
speed 385 - 577 rpm
torque 540 - 665 nm
mounting
4 bolts wheel Flange
shaft tapered shaft



Main specifiction:


Main Specifications:
Type BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2
65 80 100 125 160 200 250 315 400 475
Geometric displacement
(cm3 /rev.)		 65 80 100.9 129.8 156.8 193.4 242.5 304.3 390.8 485
Max. speed (rpm) cont. 835 800 742 576 477 385 308 246 191 153
int. 990 980 924 720 713 577 462 365 287 230
Max. torque (N·m) cont. 185 235 295 385 455 540 660 765 775 845
int. 245 345 445 560 570 665 820 885 925 930
Max. pressure drop (MPa) cont. 20.5 21 21 21 20.5 20.5 20.5 21 15.5 12
int. 27.5 31 31 31 26 26 26 24 17 14
peak 31 31 31 31 31 31 31 31 20.5 17
Max. flow (L/min) cont. 55 65 75 75 75 75 75 75 75 75
int. 65 80 95 95 115 115 115 115 115 115
Weight (kg) 9.2 9.4 9.7 10 10.2 10.5 11 11.5 12 12.4
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.


sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft

sugarcane harvester parts CB11480557 hydraulic drive motor with wheel flange, tapered shaft

hanjiu offer below types for sugarcane harvesters


404335 104-3358-006
405517 104-1029-006
408848 104-1035-006
408849 104-1422-006
CB11480557 105-1411-006
CB11480558 104-3001-006
CB11480559 104-3130-006
CB11480555 105-1308-006
