Specifications
Brand Name :
HANJIU
Model Number :
BMK2-65-E2-A-DB
Certification :
CE
Place of Origin :
China
MOQ :
100 Pieces
Price :
90 USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,Payple
Supply Ability :
10000 pieces per year
Delivery Time :
35 - 45 work days
Packaging Details :
1 pc/ inner carton, 2 pcs/ outer carton, 31x31x17cm, transport with wooden pallet, 650 pcs/ 20GP, 1300 pcs/ 40GP
Type :
Hydraulic motor
Material :
Cast iron
Displacement :
65ml/r
Port size :
7/8-14UNF O-RING
Drain line :
7/16-20UNF
Shaft :
25mm
Description

hydraulic low speed high torque motor Charlynn 2000 Series orbit motors used on beater spreaders


Quick review:

Model No.: BMK2-65-E2-A-DB


displacement 65ml/r
speed 835-990 rpm
torque 185-245nm
mounting
2 Bolt SAE A Flange
shaft
25 mm key shaft



Main specifiction:


Main Specifications:
Type BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2
65 80 100 125 160 200 250 315 400 475
Geometric displacement
(cm3 /rev.)		 65 80 100.9 129.8 156.8 193.4 242.5 304.3 390.8 485
Max. speed (rpm) cont. 835 800 742 576 477 385 308 246 191 153
int. 990 980 924 720 713 577 462 365 287 230
Max. torque (N·m) cont. 185 235 295 385 455 540 660 765 775 845
int. 245 345 445 560 570 665 820 885 925 930
Max. pressure drop (MPa) cont. 20.5 21 21 21 20.5 20.5 20.5 21 15.5 12
int. 27.5 31 31 31 26 26 26 24 17 14
peak 31 31 31 31 31 31 31 31 20.5 17
Max. flow (L/min) cont. 55 65 75 75 75 75 75 75 75 75
int. 65 80 95 95 115 115 115 115 115 115
Weight (kg) 9.2 9.4 9.7 10 10.2 10.5 11 11.5 12 12.4
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.


hydraulic low speed high torque motor Charlynn 2000 Series orbit motors used on beater spreaders


hydraulic low speed high torque motor Charlynn 2000 Series orbit motors used on beater spreaders


More BMK2 motor, BMK2 - Orbital Motor (Displacement 65 – 500 CC) available:


hydraulic low speed high torque motor Charlynn 2000 Series orbit motors used on beater spreaders







About Hanjiu:




hydraulic low speed high torque motor Charlynn 2000 Series orbit motors used on beater spreaders


HANJIU Technology specialises in the design & manufacturing of hydraulic motors , used on agricultural, amenity, construction & custom machinery and equipment from their purpose-built production facility in China, which has the latest engineering technologies, processes, together with a skilled and dynamic team.
our aim is to offer the best products to customers,
and cut their costs down, optimize their supply chain
