HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
Specifications
Brand Name :
HANJIU CHINA
Model Number :
BMV-315-4-T-D
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 pcs
Price :
Contact the selle to get the best offer
Payment Terms :
T/T,Western Union,Paypal
Supply Ability :
100000 sets per year
Delivery Time :
0 - 35 work days
Packaging Details :
Carton, Box, Pallets
Product :
Geroler Hydraulic Motor
Model No. :
BMV motor
Displacement :
400 cc
Brand :
Hanjiu
material :
cast iron
warranty :
1 year
Description


HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60


This series is the BMV series hydraulic motor
Model: BMV-315-4-T-D
Displacement: 315ml/r
Flange: 4-Ø18 Square-flange Ø160, pilot Ø160X11
Shaft: Cone shaft Ø60, parallel key 16×10×32
Rotation :Standard



Main Specifications:

Type BMV 315 BMV 400 BMV 500 BMV 630 BMV 800 BMV 1000
Geometric displacement (cm3 /rev.) 333 419 518 666 801 990
Max. speed (rpm) cont. 510 500 400 320 250 200
int. 630 600 480 380 300 240
Max. torque (N·m) cont. 920 1180 1460 1660 1880 2015
int. 1110 1410 1760 1940 2110 2280
peak 1290 1640 2050 2210 2470 2400
Max. output (kW) cont. 38 47 47 40 33 28.6
int. 46 56 56 56 44 40
Max. pressure drop (MPa) cont. 20 20 20 18 16 14
int. 24 24 24 21 18 16
peak 28 28 28 24 21 18
Max. flow (L/min) cont. 160 200 200 200 200 200
int. 200 240 240 240 240 240
Weight (kg) 31.8 32.6 33.5 34.9 36.5 38.6


* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.




HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60

HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60

Matching below types

151B3100 151B3101 151B3102 151B3103 151B3104
151B2150 151B2151 151B2152 151B2153 151B2154
151B3105 151B3106 151B3107 151B3108 151B3109
151B2155 151B2156 151B2157 151B2158 151B2159
151B3110 151B3111 151B3112 151B3113 151B3114
151B2160 151B2161 151B2162 151B2163 151B2164
151B2183 151B2184 151B2185 151B2186 151B2187
151B2188 151B2189 151B2190 151B2191 151B2192
151B3115 151B3116 151B3117 151B3118 151B3119
151B3120 151B3121 151B3122 151B3123 151B3124
151B2170 151B2171 151B2172 151B2173 151B2174


Application:
HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60

Key Applications

Construction Equipment

Excavators Driving tracks

swing mechanisms, and attachments.

Cranes Rotating and lifting operations.

Drilling rigs Powering drilling mechanisms and auxiliary functions.

Harvesters

conveyors.

Mixers Driving mixing blades

Winches

HYDRAULIC MOTOR BMV SMV OMV 315 SHAFT : Cone-shaft ø60

orbital motors

orbital motors for sale

orbital motor manufacturers

low speed orbital motors

orbital motor specifications

orbital motor size chart

orbital motors diagram

orbital motor conversion chart
