Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Specifications
Brand Name :
HANJIU
Model Number :
BMV630
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
20 Sets
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union,Paypal
Supply Ability :
100,000 Sets per year
Packaging Details :
Carton Packing, and finally with pallet or wooden box
Categories :
Hydraulic Heavy Motor
Name :
BMT160
Max.output :
cont.34.9kw/int.40kw
max torque :
cont.590N.m/int.710N.m
Flange :
square flange
Shaft :
SAE 6B shaft
Description
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO-DRIVE MOTOR
Our BMT-160-4-SL-D motors are interchangeable to the following manufacturers:
  • Danfoss, 151B0243, OMT 160 M. PTO-WELLE
  • Danfoss, 151B3018, OMT 160
  • Hydromot CPMT160SL
Product Specifications
Categories Hydraulic Orbit Motor
Name BMT160
Max. Output cont.27.7kw/int.32kw
Max. Torque cont.470N.m/int.560N.m
Flange Square Flange
Shaft SAE 6B Shaft
BMT Series Specifications Comparison
Type BMT 160 BMT 200 BMT 230 BMT 250 BMT 315 BMT 400 BMT 500 BMT 630 BMT 800
Displacement (cm³/rev.) 161.1 201.4 232.5 251.8 326.3 410.9 523.6 629.1 801.8
Max. speed (rpm) cont. 625
int. 780		 cont. 625
int. 750		 cont. 536
int. 643		 cont. 500
int. 600		 cont. 380
int. 460		 cont. 305
int. 365		 cont. 240
int. 285		 cont. 196
int. 233		 cont. 154
int. 185
Max. torque (N m) cont. 470
int. 560
peak 669		 cont. 590
int. 710
peak 838		 cont. 670
int. 821
peak 958		 cont. 730
int. 880
peak 1036		 cont. 950
int. 1140
peak 1346.3		 cont. 1080
int. 1260
peak 1450.3		 cont. 1220
int. 1370
peak 1643.8		 cont. 1318
int. 1498
peak 1618.8		 cont. 1464
int. 1520
peak 1665
Max. output (kW) cont. 27.7
int. 32		 cont. 34.9
int. 40		 cont. 34.7
int. 40		 cont. 34.5
int. 40		 cont. 34.9
int. 40		 cont. 31.2
int. 35		 cont. 28.8
int. 35		 cont. 25.3
int. 27.5		 cont. 22.2
int. 26.8
Max. pressure drop (MPa) cont. 20
int. 24
peak 28		 cont. 20
int. 24
peak 28		 cont. 20
int. 24
peak 28		 cont. 20
int. 24
peak 28		 cont. 20
int. 24
peak 28		 cont. 18
int. 21
peak 24		 cont. 16
int. 18
peak 21		 cont. 14
int. 16
peak 19		 cont. 12.5
int. 13
peak 16
Max. flow (L/min) rated 80
cont. 100
int. 125		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150		 rated 100
cont. 125
int. 150
Max. inlet pressure (Mpa) cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30		 cont. 21
int. 25
peak 30
Weight (kg) 19.5 20 20.4 20.5 21 22 23 24 25
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR
Hydraulic Motor CPMT160SL,151B0243, OMT 160 PTO DRIVE MOTOR

orbital motor is widely used in several core systems of harvesters:

Walking drive system: In the hydrostatic transmission system, it utilizes its low-speed and high-torque characteristics to drive the walking wheels or tracks of the harvester either directly or through a simple deceleration mechanism. By adjusting the hydraulic oil flow, the travel speed can be infinitely adjusted to ensure the flexibility and stability of the machine in complex terrain such as slopes and mud.

Cutting platform control system: Provide strong and smooth driving force for the rapid elevation of the cutting platform, and support the automatic profiling function of the cutting platform according to the terrain (control the elevation cylinder).

Material Conveyor System: Drive the conveyor chain, agitator, elevator and other mechanisms between the cutting platform to the threshing drum and the cleaning device to the grain bin to provide continuous and stable speed and torque to ensure the smooth and unobstructed flow of crop materials.

Attachment drives: for bin unloading agitators, straw chopping devices or baling devices, etc. The modular design facilitates integration and installation.
