Specifications
Model Number :
ZP50-4
MOQ :
100 Sets
Delivery Time :
25 - 35 work days
Spool :
4 banks
Brand Name :
HANJIU
Place of Origin :
CHINA
Payment Terms :
L/C,T/T,Western Union,Western Union
Max operation pressure :
250 bar
Apply to :
TELESCOPIC TRUCK , PLATFORMS
Certification :
CE
Price :
Contact the seller to get a quote
Item :
monoblock valve
Supply Ability :
300000 sets per year
Material :
cast iron
control type :
ZP50-4
Packaging Details :
Carton, Box, Pallets
Description


Hydraulic monoblock valve 4 sections-45l-min ORTA MB25-4 for TELESCOPIC TRUCK


type details:

type code:ZP50-4 matching MB25-4


The MB25/4--ZP50-4 is a 4-spool monoblock hydraulic directional control valve used to direct and regulate hydraulic fluid flow. Built for mobile applications and industrial machinery, it operates at a maximum flow rate of 45 liters per minute (12 GPM) and pressures up to 250 bar (approx. 3600 PSI).


flow rate:50liters

spool type:4 spools

pressure:200bar

inlet port:G1/2

working port:G3/8

control: 3position double acting,A/B open at central

outlet port:G3/8



Control type:
manual control


Circuit type: parallel


Application :


Cranes, Telescopic boom fork lifts, Back-hoe Excavators and Compactors,Sanitation Vehicles



flow rate 50 liters
number of spools 4 banks
inlet section valve side inlet, with relief valve
relief valve set pressure 200bar
inlet port size G1/2
spool type 3 positon, double acting
handle side arrangement standard type
spool cap side arrangement 3position, spring return,manual control,detent control,
working section arrangement standard type
work port size G3/8
outlet section type top outlet,side
outlet port size G1/2
