MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical
Specifications
Brand Name :
HuaWei
Model Number :
XGLD
Place of Origin :
Guangdong, China
MOQ :
Negotiable
Price :
Negotiable
Model number :
XGLD
Port quantity :
8 XE-PON
Forwarding Rate :
80 Gbit/s
Dimensions (W x D x H) mm :
23 x 237 x 396mm
Maximum Power waste :
61W
Working temperature :
-40℃~+65℃
MAX Split ratio :
1: 256
Warranty :
1 Year
Description

MA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical

HuaWei MA5800 series GPON EPON OLT interface board XGLD 10 Gigabit 8-port 10G symmetrical

Product Description

XGLD single board is a 8-port XG-PON OLT interface board,which cooperates with ONU to realize EPON access service.

Product Features

*High Density,energy Saving,low power consumption,support 2048 access users

*Manual shutdown of idle PON port to avoid power waste

*Supporting the maximum distance difference between two ONUs and PON ports under the same PON port

*40 km,simplified network planning

*Intelligent Management Channel

*Level 4 HQoS to Improve User Experience

*9216 Jumbo frame,greatly improving transmission efficiency

*Easy to operate and maintain

*Real-time hooligans ONU detection and isolation to ensure stable operation of business

*Variable Length OMCI to Improve Upgrade Efficiency and Shorten Business Interruption Time

*1:256eOTDR,Accurate Fault Responsibility Division and Fast Fault Location

External interface

8 XG-PON Port (SFP+ Optical Module):

Maximum spectral ratio:1:256

Product Specifications
Specification
XGLD
Port quantity
8
MAX Split ratio
1: 256
Forwarding Rate
80Gbit/s
Rate model
Asymmetric Rate Model
Maximum Number of T-CONT
2048
Maximum Number of Service Flows Supported by the Board
16376
Maximum frame length
2052 bytes
Maximum Number of MAC
16384
Maximum differential fibre distance (km)
40
Board supporting downstream FEC
Yes
Board supporting upstream FEC
Yes
CAR
Yes
D-CCAP
No
Temperature query and high temperature alarm
Yes
Automatic power shutdown in case of a high temperature
Yes
Rogue ONT detection
Yes
1588v2
V100R017C10Yes
High temperature automatic concern
Yes
Rogue ONT Detection and Isolation Support
Yes
Working temperature
-40℃~+65℃
Maximum Power waste
61w
Dimensions (W x D x H)
490 mm x 325mm x 75mm

MA5800 Series GPON EPON HuaWei OLT Board 10G SymmetricalMA5800 Series GPON EPON HuaWei OLT Board 10G Symmetrical

FAQ

Q: Can we get samples?

A: Yes, but we need to charge a sample fee.

Q: Can you offer better prices? And discount?

A: Yes, Powerlink does not have a minimum order quantity, but different quantities have different prices.

Q: Can you take care of the goods?

A: If you wish, we will organize and arrange all the deliveries to your office.

Q: How about the payment item?

A: T/T, PAYPAL, Western Union.

Q: Delivery time?

A: Sample order, 3-5 working days. For larger orders, 5-8 working days after receiving the deposit.

Q: How long is your warranty period?

A: The warranty period is 12 months. This warranty does not cover damage caused by man-made damage, improper maintenance, improper use, negligence, normal wear and tear and force majeure (such as natural disasters, earthquakes, fires, etc.).

CONTACT INFORMATION

HELEN:Wechat/Whatsapp+8613590164558

Email:best-helen@foxmail.com/helen@toptodaynetwork.com
