Description of MCUD
The H801MCUD board is a Mini Control Unit Board. It is the core of the system control and service switching and aggregation. The H80MCUD board can also function as the management and control core of the integrated network management system (NMS). It communicates with service boards about the key management and control information through the master/slave serial port and inband GE/10GE channel. In this manner, the H801MCUD board configures, manages, and controls the device, and also implements the simple route protocol functions.
| 1. As an OLT in a GPON network to work with the ONU and ONT. |
| 2. Supports rich network applications, like FTTH / FTTB / FTTC. |
| 3. Meets the network requirements of base station transmission, IP private line interconnection, and multi-ISP wholesale. |
| 4. Supports the P2P FE optical access. By cooperating with ONT, MA5680T provides users with the P2P FTTH access. |
| Blackplane bus switching capacity - 3.2 Tbit/s | Max. GE upstream ports in a shelf - 4 |
| System L2 packet forwarding rate - 726 Mpps | Max. 10GE upstream ports in a shelf - 2 (X1CA) 4 (X2CA) 4 (X2CS) |
| control board switching capacity - 480 Gbit/s | Max. GPON ports in a shelf - ETSI service shelf: 128 |
VoIP service
After passing through the ONT, the VoIP packets reach the MA5680T. The MA5680T then transmits the packets to the NGN network, or to the PSTN network through an MG.
Data service
The PCs are connected to the MA5680T through the ONTs. The PCs are then connected to the IP network through the BRAS.
Video service
The video traffic is sent to the ONTs in the IPTV or cable television (CATV) mode.
Specification of MCUD
| Port Type | Port | Description |
| Upstream port | GE optical/electrical port | use the Single-mode / multi-mode SFP optical transceivers. supports different transmission by different SFP. Multi-GE upstream transmission is supported to meet the multi-edge network requirements of the carrier. |
| 10GE optical port | the 10GE upstream transmission |
| E1 port | the E1 upstream transmission |
| STM-1 port | the upstream transmission through the STM-1 optical port. supports ESFP/SFP module |
| Service port | GPON port | the GPON access. Maximum upstream rate: 1.244 Gbit/s Maximum downstream rate: 2.488 Gbit/s |
| P2P optical port | P2P Ethernet optical access, 100 Mbit/s. |
| Ethernet optical port | GE subtending |
| Maintenance port | Maintenance serial port | for local and remote maintenance |
| Environment monitoring serial port | the monitoring device collects various environment parameters. this port reports to the MA5680T. |
