Specifications
Place of Origin :
Guangdong, China
Brand Name :
Huawei
Model Number :
MA5603T
MOQ :
Negotiable
Price :
Negotiable
Delivery Time :
5-8days
Packaging Details :
new in the box.
Certification :
FCC,CCC,CE
Product name :
MA5603T
Brand :
huwewei
Condition :
new and original
service :
voice/CATV/Ethernet/NGN
skype :
toptoday-michelle_1
Selling Units :
Single item
Single package size  :
85X55X30 cm
Single gross weight :
15.000 kg
Package Type :
New in the huawei box .
Description

HUAWEI Optical Network (GPON) Optical Line Terminals SmartA MA5603T OLT

Product specification:

Suitable machine phase

Indoor cabinet: N60E - 18 outdoor cabinet: F01S300,F01T500,F01T300

Veneer configuration

Main control board: 2 slots
Business board: 6 slots
Universal interface board: 1 slot
Uplink interface board: 2 slots
Power interface board: 2 slots

Support the main control board and exchange capacity

SCUN/SCUK:480Gbit/s(The main standby mode),960Gbit/s(Load sharing model)

SCUH/SCUV:960Gbit/s(The main standby mode),1920Gbit/s(Load sharing model)

System layer packet forwarding rate

SCUN/SCUK:726Mpps(The main standby mode),1452Mpps(Load sharing model)

SCUH/SCUV:1428Mpps(The main standby mode),2856Mpps(Load sharing model)

Exchange forward delay

Has low forward delay. The 100Mbit/s Ethernet port sends 64Byte Ethernet packets with a latency of less than 20 mics.

Full load error rate

When the port is at full load, the bit error rate (bit error rate) is <10 e-7.

Maximum number of access ports supported in a single box

GPON,EPON

96

10G GPON,10G EPON

48

P2P FE,P2P GE

288

Product Descriptions:

The MA5603T(MA5800T) /MA5600T/MA5608T, functioning as an integrated optical-copper access equipment, provides the integrated broadband and narrowband access and FTTx optical access services that feature high rate, high bandwidth, and high quality. It can function as an OLT, MSAN, or IP DSLAM. The MA5600T is a large-capacity device, the MA5603T is a medium-capacity device and the MA5608T is a small-capacity device.
Supports the 10G GPON and GPON access service. All the three can function as an optical line terminal (OLT) in the GPON system, working with the optical network terminal (ONT) or other optical network units (ONUs).
Supports the point-to-point (P2P) FE/GE optical access and provides users with the P2P FTTH access by cooperating with the ONT.
Provides the voice service solution based on the Session Initiation Protocol (SIP) and H.248, supports the POTS port to implement the voice service, fax service, narrowband modem service, and various supplementary services.
Provides the E1/N*64k private line service through the TDM SHDSL board. And H802EDTB board supports the TDM SHDSL feature.
Supports broadband access services such as ADSL2+, VDSL2, and SHDSL, enhancing the xDSL function.
