1.45 Inch Full Color OLED Display 160x128 Pixels 35 Pins SEPS525 Controller

LIMITO OLED Description:

UG-6028GDEAF01 is a color OLED display. OLED (Organic Light Emitting Diode) is a new generation technology with brighter, clearer images and more agile response speed. This 1.45-inch UG-6028GDEAF01 OLED display consists of 160 x 128 monochrome dots. This OLED module is lightweight, low power consumption, small in size, and has different interfaces to choose from; It is the 8-/9-bit 80XX Parallel, 4-wire SPI, 6-bit RGB I/F Interface.

The effective area size (diagonal) of this product UG-6028GDEAF01 is 1.45 inches, the module size is 35.80 x 45.30 x 1.60 (mm), and the Active area size is 28.78 x 23.024 (mm). This 1.45-inch OLED display is equipped with IC SEPS525 and has a high contrast ratio of 20000:1. The voltage range of the logic power supply is 1.65V-3.5V, with a typical value of 3V. It is very suitable for applications such as medical equipment, POS systems, white goods, home applications, industrial instruments, automation, audio-visual display systems, personal care products, household appliances, car displays, dynamic information displays, etc.

LIMITO OLED Specification:

LIMITO OLED Mechanical Drawing

LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner & Lighter & Durable

Wide operation Temperature-40°c~+85°c

Self-emitting, no need for a backlight

LIMITO OLED Application:

Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key

Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box

Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen

Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment

Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
