Specifications
Brand Name :
Limito
Model Number :
UG-2896GDEAF11
Place of Origin :
China
Certification :
RoSH, Reach
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
Delivery Time :
3-5days
Payment Terms :
T/T, Paypal
Supply Ability :
7kk/M
Diagonal Screen Size :
1.27
Drive IC :
SSD1351U3
Interface :
8-bit 68XX/80XX Parallel, 3-/4-wire SPI
Life Time :
20000
Operating Temperature :
-30~70°C
Number of Pixels :
128x96
Brightness :
100
Description

1.27inch RGB OLED Display Module 128x96 Resolution 262K Colors SPI Interface

LIMITO OLED Description:

  • Compact Size: At 1.27 inches, this display is small enough to fit in tight spaces, making it ideal for portable devices and wearables.
  • High Resolution: With a resolution of 128x96 pixels, the display delivers clear and detailed images, suitable for text and graphics.
  • Vibrant Color Range: Supporting 262K colors, the RGB OLED technology provides rich colors and deep blacks, enhancing visual quality.
  • SPI Interface: The Serial Peripheral Interface (SPI) allows for fast data transfer, facilitating smooth updates and responsiveness in applications.
  • Low Power Consumption: OLED technology is energy-efficient, making this display suitable for battery-powered devices.
  • Wide Viewing Angles: The display offers excellent visibility from various angles, ensuring clear viewing for multiple users.
  • Fast Response Time: OLED displays typically have quick refresh rates, making them ideal for dynamic content and animations.
  • Easy Integration: Compatible with various microcontrollers and development boards, this module is user-friendly for developers and hobbyists.
  • No Backlight Required: As OLEDs emit their own light, there’s no need for a backlight, allowing for a thinner and lighter design.

​

LIMITO OLED Specification:

Part Name: OLED Display Module
Limito Part ID:

UG-2896GDEAF11

Display Mode:

Passive Matrix

Display Color:

262,144 Colors (Maximum)

Drive Duty:

1/96 Duty

Number of Pixels:

128 (RGB)x 96

Panel Size:
33.70 x 26.90 x 1 .60 (mm)

Active Area:

25.708 x 19.28 (mm)

Pixel Pitch:

0.067 x 0.201 (mm)

Pixel Size:

0.047 x 0.185(mm)

LIMITO OLED Mechanical Drawing

1.27 Inch Color Oled Screen 128x96 262K Colors SPI Interface

LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner & Lighter & Durable

Wide operation Temperature-40°c~+85°c

Self-emitting, no need for a backlight

LIMITO OLED Application:

Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key

Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box

Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen

Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment

Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
