Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine
Specifications
Brand Name :
HKJ
Model Number :
DXDK-40Ⅱ/150Ⅱ
Certification :
ISO90001-2000
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
20 SETS/MONTH
Delivery Time :
20 WORKS DAYS
Packaging Details :
Standard exporting wooden case
Motor :
3 servo motror
Materials :
304 stainless steel
Screen :
Touch screen
Bag size :
55-110mm/30-80mm
Capacity :
50-110 bags/min
Product name :
Automatic Granular Packing machine
Description

Automatic Granular Packing Machine

Product Category:Vertical Packing Machine

Product Name:Automatic Granular Packing Machine

Item No.:DXDK -40Ⅱ/150Ⅱ

Applications:

The machine is suitable for packing non sticky,bulk or granular material, such as medical pills,Food stuffs, plant seeds, washing powder, coffee, sugar, desiccant, etc.

Features

1 The integrated progress of bag making,measuring filling, sealing cutting, counting and hot pressing codes can be done automatically.

2 High-performance hot sealing structure makes packing neat and fine, and gastight.

3 Special inner structure makes all operation could be done on the screen, which makes operating easier

4 New fully closed feeding structure makes measuring more easy-cleaned and more satisfied the sanitary standard

5 Other fuctions such as material alarm, no paper alarm and alarm for fused heaters,etc

Packing Material:

Several kinds of heat seal lamination, such as PET/Plated AL/PE,PET/PE,PAPER/PE,Nylon,etc.

2, Specification:

Model No. DXDK-40Ⅱ DXDK-150Ⅱ
Bag Size (L)50-110mm/(W)30-80mm (L)70-150mm/(W) 70-115mm
Capacity 50-110 bags/min 35-60 bags/min
Mix Filling Range 40ml 150ml
Power 220V,50HZ,1.5KW 220V,50HZ,1.9KW
Weight 320 KG340 KG
Dimensions 600*790*1780mm 700*800*1900mm

3, Main clectric parts brand list

A, Packing machine

1 Touch screen Weinview (Taiwan)
2 Servo motor Mitsubish(Japan)
3 Servo amplifier Mitsubish(Japan)
4 PLC Mitsubish(Japan)
5 Solid state relay CHINT( China)
6 Air switch Fuji(Japan)
7 Kubler system for electricity transmission Mercotac( USA)

B,Trimming and feeding coveyor

1 Servo drive Mitsubish(Japan)
2 Servo motor Mitsubish(Japan)
3 Photo sensor Autonics( Korea)

Fully Automatic Granule Packing Machine , Tea / Coffee Powder Packing MachineFully Automatic Granule Packing Machine , Tea / Coffee Powder Packing MachineFully Automatic Granule Packing Machine , Tea / Coffee Powder Packing Machine

Remark:

1, Package: Standard export wooden case

2, Delivery time: 40 days from receive advance payment

3, We will supply full set of spare parts and tooling when machine shipping

4, Warranty: 1 year, after one year, we will supply technical service
