Specifications
Brand Name :
NNT
Model Number :
NITV 2030
Certification :
CE / ISO9001
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
T/T
Supply Ability :
500 pcs within 7 working days
Delivery Time :
5-7 work days
Packaging Details :
Carton box individually
Description
NITVX2030 Series High-Pressure Proportional Valves
Product Overview

NNT NITVX2030 Proportional Valve with 2.0 MPa Max Pressure, 50 ms Fast Response, and Digital Display for Precision Control


Advanced Pressure Control Technology

The NNT NITVX2030 series represents the latest innovation in high-pressure proportional valve technology. Designed for precision control in demanding industrial environments, these valves offer exceptional stability, fast response times, and reliable performance.

With a maximum operating pressure of 2.0 MPa, the NITVX2030 series is ideal for applications requiring precise pressure regulation, such as pneumatic testing, clamping force control, and process automation systems.

The integrated digital display and intuitive control interface provide real-time monitoring and adjustment capabilities, making integration into automated systems seamless and efficient.

Key Features

High-Pressure Performance

Operates at pressures up to 2.0 MPa with exceptional stability and precision across the entire pressure range.


Fast Response Time

Response time of less than 50 ms ensures rapid adjustment to pressure changes for dynamic system requirements.


Digital Control Interface

Integrated digital display and intuitive controls allow for precise setting and monitoring of pressure parameters.


Robust Construction

Built with durable materials to withstand harsh industrial environments and ensure long-term reliability.


Compact Design

Space-saving footprint allows for easy integration into existing systems without requiring extensive modifications.


Easy Integration

Compatible with standard industrial communication protocols including IO-Link, analog, and serial communication.

Technical Specifications
Parameter Specification
Model Series NITVX2030
Maximum Operating Pressure 2.0 MPa
Controlled Pressure Range 0.005 to 2.0 MPa
Response Time ≤ 50 ms (0.1 to 0.9 MPa)
Repeatability ±0.5% of full scale
Linearity ±1.0% of full scale
Hysteresis ±0.5% of full scale
Supply Voltage 24 VDC ±10%
Current Consumption 220 mA max
Control Signal 0-5 V, 0-10 V, 4-20 mA
Communication Interface IO-Link V1.1, RS-485 (Modbus RTU)
Port Size Rc1/4, Rc3/8, NPT1/4, NPT3/8
Ambient Temperature 0 to 50°C (No freeze)
Protection Rating IP65
Weight Approx. 650 g
Industrial Applications
Factory Automation

Precise pressure control for assembly, clamping, and testing equipment

Automotive Manufacturing

Brake testing, tire inflation systems, and component testing

Packaging Machinery

Controlled pressure for filling, sealing, and labeling operations

Robotic Systems

Force control for grippers and end effectors in robotic applications

Laboratory Equipment

Precise pressure regulation for analytical and testing instruments

Test & Measurement

Pressure calibration and leak testing systems
