Specifications
Brand Name :
NNT
Model Number :
NITV1050
Certification :
CE
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T
Supply Ability :
500pcs within 7 working days
Delivery Time :
5-7 working days
Packaging Details :
Carton box individually
Description

NNT NITV1050 Electric Pneumatic Pressure Regulator | Precision Air Pressure Control

The NITV1050 series provides accurate and responsive proportional control for pressure and flow applications in automated systems

NNT NITV1050 Electric Pneumatic Pressure Regulator with 1.0 MPa Max. Pressure, ±1% F.S. Linearity, and 20 ms Response Time for Precision Control

Advanced Proportional Control for Modern Automation

The NNT NITV1050 Series Electrical Proportional Valve delivers precise control of pressure or flow in response to an electrical input signal. With its advanced solenoid design and digital control capabilities, it enables accurate and repeatable proportional control for demanding industrial applications.

This proportional valve series features rapid response times, excellent linearity, and minimal hysteresis, making it ideal for applications requiring precise pressure or flow regulation. The compact design and digital communication interfaces allow for easy integration into modern automated systems.

  • High precision proportional control with excellent linearity
  • Fast response time for dynamic control applications
  • Digital communication interfaces (IO-Link, analog, PWM)
  • Compact and lightweight design for space-constrained installations
  • Easy calibration and setup with minimal hysteresis
  • Suitable for both pressure and flow control applications

Key Features & Benefits

High Precision Control

Excellent linearity and minimal hysteresis ensure accurate and repeatable proportional control performance.

Fast Response Time

Rapid response to control signals enables dynamic adjustment for time-critical applications.

Multiple Interface Options

Support for analog voltage/current, PWM, and digital IO-Link communication for flexible integration.

Compact Design

Space-saving form factor with lightweight construction ideal for applications with size constraints.

Easy Calibration

Simple calibration procedures and minimal setup requirements for quick installation and commissioning.

Robust Construction

Durable design with high-quality components for reliable operation in industrial environments.

Typical Control Performance

Linear response characteristics with minimal hysteresis

Control Linearity: Better than ±1% F.S.
Hysteresis: Less than 0.5% F.S.

Technical Specifications

Detailed technical data and performance specifications for the NITV1050 series

1.0 MPa Max. Pressure
±1% F.S. Linearity
20 ms Response Time
IO-Link Digital Interface
General Specifications
Series NITV1050
Type Electrical Proportional Control Valve
Control Function Pressure Regulation / Flow Control
Maximum Operating Pressure 1.0 MPa
Linearity Better than ±1% of Full Scale
Hysteresis Less than 0.5% of Full Scale
Response Time 20 ms or less (10 to 90% of control range)
Repeatability Better than ±0.5% of Full Scale
Electrical & Interface Specifications
Input Signal Options Analog signal, ModBus 485
Digital Communication IO-Link V1.1 compatible
Power Supply 24V DC ±10%
Port Sizes 1/8", 1/4" (NPT, Rc, G threads available)
Temperature Range 0 to 50°C (Ambient and Fluid)
Protection Rating IP65
Media Compatibility Compressed Air (Non-lubricated or Lubricated)

NNT NITV1050 Electric Pneumatic Pressure Regulator with 1.0 MPa Max. Pressure, ±1% F.S. Linearity, and 20 ms Response Time for Precision Control

Application Industries

The NITV1050 series electrical proportional valves are designed for precision control in various industrial applications

Robotic Force Control

Precise pressure regulation for robotic grippers and end-effectors requiring controlled force application.

Packaging Machinery

Accurate pressure control for sealing, cutting, and forming operations in packaging equipment.

Automotive Testing

Precise pressure simulation for brake testing, leak testing, and component validation in automotive applications.

Process Control

Flow and pressure regulation in chemical processing, food production, and pharmaceutical manufacturing.

Machine Tool Clamping

Controlled clamping force for workholding fixtures in CNC machines and machining centers.

Semiconductor Manufacturing

Precise pressure control for wafer handling, component placement, and delicate assembly operations.
