48-Port Gigabit + 4x 10G SFP , Stackable & Secure Huawei Switch S5735R-48T4S-A2
48-Port Gigabit + 4x 10G SFP , Stackable & Secure Huawei Switch S5735R-48T4S-A2
Specifications
Brand Name :
Huawei
Model Number :
S5735R-48T4S-A2
Layer Support :
Layer 2 and Layer 3 switching
Qos :
Supports 8 queues per port
Poe :
Support
Virtualization Support :
VXLAN, NVGRE, and MPLS
Packet Buffer Size :
4MB
Product Size :
2U
Network Standards :
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Vlan Standards :
IEEE 802.1Q
Supported Protocols :
IPv4, IPv6, MPLS, OSPF, BGP, IS-IS
Storage Temperature :
-40°C to 70°C
Qos Support :
Supports 8 queues per port
Stackable :
Yes/No
Power Supply :
AC
Stacking Bandwidth :
160 Gbps
Description

48-Port Gigabit + 4x 10G SFP , Stackable & Secure Huawei Switch S5735R-48T4S-A2

The Huawei S5735R-48T4S-A2 is a high-performance Layer 3 Gigabit switch designed for enterprise and campus networks, combining 48x 1G Ethernet ports and 4x 10G SFP+ uplinks for scalable, high-bandwidth connectivity. Ideal for medium-to-large businesses, data centers, and smart campuses, it delivers advanced security, cloud management, and energy efficiency in a compact form factor.

Key Features:

  • High-Density Ports: 48x 10/100/1000BASE-T ports + 4x 10G SFP+ slots for flexible uplinks or stacking.

  • Layer 3 Routing: Supports OSPF, BGP, VRF, and static routing for complex network segmentation.

  • Stacking (Hybrid Ports): Huawei Stack technology allows up to 16 units to operate as a single logical switch.

  • Enterprise Security: ACLs, 802.1X, MACsec, and anti-DDoS features for hardened network protection.

  • Cloud & AI Management: Compatible with iMaster NCE and eSight for zero-touch provisioning and AI-driven analytics.

  • Energy-Efficient: IEEE 802.3az (EEE) compliance reduces power consumption by up to 30%.

Technical Specifications:

Parameter Specification
Ports 48x 1G RJ45 + 4x 10G SFP+
Switching Capacity 336 Gbps
Forwarding Rate 126 Mpps
Stacking Up to 16 units, 160 Gbps bandwidth
Power Supply AC (dual PSU optional)
Dimensions (WxDxH) 442 x 420 x 44 mm
Operating Temp. 0°C to 45°C

Why Choose This Huawei Switch?

  1. Future-Proof Scalability: 10G uplinks and stacking support growing bandwidth demands.

  2. Carrier-Grade Reliability: 99.999% uptime with ERPS (<50ms failover) and BFD.

  3. Simplified SDN Integration: Agile Controller compatibility for automated VLAN/ QoS policies.

Deploy the S5735R-48T4S-A2 as an access/aggregation switch for offices, hospitals, or IoT networks. Its low-latency forwarding and enterprise-grade security make it ideal for VoIP, video surveillance, and cloud applications.
