High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks
Specifications
Brand Name :
Huawei
Model Number :
S5731-S8UM16UN2Q
Uplink :
4 x 1G SFP ports
Vlan Standards :
IEEE 802.1Q
Product Type :
Network Interface Cards
Port Number :
24
Humidity :
5% to 95% (non-condensing)
Stacking Support :
Yes
Poe :
Support
Port Speed :
10/100/1000/10000 Mbps
Operating System :
Huawei Versatile Routing Platform (VRP)
Packet Buffer Size :
4MB
Stacking Capability :
Up to 9 switches
Connectivity Technology :
Wired
Power Consumption :
Max. 350W
Packet Buffer :
2 MB
Description

High-Density 24-Port Huawei Switch With 10G Uplink & Cloud Management For Enterprise Networks

The Huawei S5731-S8UM16UN2Q is a high-performance Gigabit Ethernet switch designed for enterprise and campus networks, offering flexible connectivity, high-speed uplinks, and intelligent cloud management. With 8x 1G copper ports, 16x 1G SFP fiber ports, and 2x 10G SFP+ uplinks, this switch ensures scalable bandwidth for demanding applications like VoIP, video surveillance, and cloud services.

Key Features & Benefits

✔ High-Density Hybrid Ports – 24-port (8G + 16SFP) design supports copper and fiber connections, ideal for diverse network environments.
✔ 10G Uplink for Future-Proofing – Two 10G SFP+ ports eliminate bottlenecks in aggregation and core layers.
✔ Cloud-Based Management – Supports SDN, Huawei CloudCampus, and Agile Controller for simplified network automation and monitoring.
✔ Enterprise-Grade Security – Features MACsec encryption, ACLs, and anti-DDoS to protect against cyber threats.
✔ iPCA Network Analytics – Real-time latency and packet loss detection for faster troubleshooting.
✔ Energy-Efficient & Reliable – Low power consumption (15W typical) and dual-power redundancy (optional) for 24/7 uptime.

Technical Specifications (Huawei S5731-S8UM16UN2Q)

Parameter Specification
Port Configuration 8x 10/100/1000BASE-T, 16x 1G SFP, 2x 10G SFP+
Switching Capacity 56 Gbps
Forwarding Rate 42 Mpps
Power Supply AC (Dual PSU optional)
Dimensions (WxDxH) 442 x 220 x 43.6 mm
Operating Temp. 0°C to 45°C
Management Web, CLI, SNMP, OpenFlow (SDN-ready)

Ideal Use Cases

✅ Enterprise Networks – Reliable access/aggregation for offices and data centers.
✅ Campus Wi-Fi Backbone – Supports CloudCampus for unified wired/wireless management.
✅ Industrial Environments – Optional extended temperature models for harsh conditions.

Upgrade to the Huawei S5731-S8UM16UN2Q for a scalable, secure, and smart-managed network solution. Shop now or contact Huawei partners for bulk pricing!
