Specifications
Brand Name :
Huawei
Model Number :
S5731-L4P2S-RUA
Forwarding Rate :
95.2 Mpps
Qos Features :
8 queues per port, DiffServ, WRED
Layer :
Layer 2
Switch Capacity :
176Gbps
Port Speed :
10/100/1000Mbps
Forwarding Mode :
Store-and-Forward
Interface Type :
Ethernet
Speed :
10/100/1000 Mbps
Packet Buffer :
4 MB
Form Factor :
Plug-in card
Power Frequency :
50/60 Hz
Forwarding Performance :
56 Gbit/s
Qos Support :
Yes
Redundancy Support :
VRRP, HRP, BFD
Description

High-Performance Huawei Switch With 4G/2E Ports & PoE+ Support For Enterprise Networks

The Huawei S5731-L4P2S-RUA is a next-generation Gigabit Ethernet switch designed for enterprise networks, offering high-speed connectivity, advanced PoE+ support, and intelligent management for seamless business operations. With 4x Gigabit SFP ports (4G) and 2x 10/100/1000BASE-T ports (2E), this compact yet powerful switch ensures flexible deployment in office networks, campus environments, and surveillance systems.

Key Features & Benefits

✔ Power over Ethernet+ (PoE+) – Supports IEEE 802.3af/at, delivering up to 30W per port to power IP phones, wireless APs, and IP cameras without extra wiring.
✔ High-Speed Switching Capacity – 56Gbps switching capacity ensures smooth data transfer, ideal for bandwidth-intensive applications.
✔ Enterprise-Grade Security – Features MACsec encryption, ACLs, and port isolation to protect against unauthorized access.
✔ Smart Cloud Management – Compatible with eSight and CloudCampus, enabling remote monitoring, automated configurations, and real-time troubleshooting.
✔ Energy-Efficient Design – Huawei’s Green Ethernet technology reduces power consumption by up to 30%, lowering operational costs.

Technical Specifications (Huawei S5731-L4P2S-RUA)

Parameter Specification
Ports 4x 1G SFP, 2x 1G RJ45
PoE+ Support Yes (30W per port)
Switching Capacity 56Gbps
Forwarding Rate 41.66Mpps
Security Features MACsec, ACLs, DoS Protection
Management Web, CLI, eSight, SNMP
Power Consumption <12W (non-PoE), <150W (PoE max)

Ideal Use Cases

  • Office Networks: Reliable connectivity for workstations, printers, and VoIP phones.

  • Surveillance Systems: PoE+ powers IP cameras while ensuring high-bandwidth video streaming.

  • Wi-Fi 6 Backhaul: Gigabit uplinks support high-speed wireless access points.

Why Choose This Huawei Switch?

The S5731-L4P2S-RUA combines performance, security, and ease of management, making it a cost-effective solution for SMBs and enterprise branch networks. Its compact design, energy efficiency, and cloud-ready capabilities ensure future-proof networking.
