Specifications
Brand Name :
Ruckus
Place of Origin :
Beijing, Beijing,China
Packaging Details :
Brand new original unopened
Supply Ability :
50 Piece/Pieces per Day
MOQ :
2 pieces
Price :
$450.00/pieces 2-199 pieces
Model Number :
901-R720-WW00
Max. LAN Data Rate :
1000Mbps
With Modem Function :
NO
Standards And Protocols :
Wi-Fi 802.11ac, Wi-Fi 802.11b, Wi-Fi 802.11g, Wi-Fi 802.11n
Wi-Fi Supported Frequency :
2.4G & 5G
Supports WDS :
No
Supports WPS :
No
Wi-Fi Transmission Standard :
802.11b
Wired Transfer Rate :
None
2.4G Wi-Fi Transmission Rate :
600Mbps
Encryption Type :
WPA2, WPA, WEP
Private Mold :
NO
Products Status :
New, NIB Original
Type :
Wired and Wireless
Application :
Home
Function :
FireWall, QoS, VPN
LAN Ports :
2
WAN Ports :
1 x10/100/1000Mbps
5G Wi-Fi Transmission Rate :
1300Mbps
Product name :
901-R720-WW00
Warranty :
1 Year
Model :
Indoor wireless access point
DC Input :
12 VDC 2A
Physical Size :
23 cm (L), 21 cm (W), 6 cm (H)
Weight :
1.12 kg (2.5 lb.)
PHY Data Rates :
* Up to 800 Mbps (2.4GHz) * Up to 1733 Mbps (5GHz)
Description

Ruckus 901-R720-WW00: Powering High-Density Wi-Fi

The Ruckus 901-R720-WW00 is a robust indoor 802.11ac Wave 2 access point, engineered for demanding, high-density wireless environments.

Superior Performance & Capacity

Delivering up to 2.333 Gbps combined throughput with 4x4:4 MU-MIMO, the R720 efficiently handles hundreds of concurrent users. It excels where typical Cisco Wireless AP solutions might face congestion in crowded spaces.

Intelligent Wi-Fi for Reliability

Patented BeamFlex+™ adaptive antennas and ChannelFly® technology ensure optimal coverage and minimal interference. This intelligent approach delivers consistent, reliable performance beyond standard network setups, including those centered on a generic Cisco Network Switch.

Flexible Connectivity

Equipped with 2.5 Gigabit and 1 Gigabit Ethernet ports, plus PoE+ for power, the R720 offers ample backhaul. Its USB port also supports future IoT module expansion.

Adaptable Management

Manage the R720 effortlessly with options like controller-less Ruckus Unleashed, or scale up with SmartZone controllers and Ruckus Cloud.

Ruckus 901-R720-WW00 Detailed Parameters

For a comprehensive look at its technical capabilities, here are the detailed specifications:

Parameter Category Parameter Specification
Wireless Wi-Fi Standard 802.11ac Wave 2 (backward compatible with a/b/g/n)
Frequency Bands Dual-band (2.4 GHz & 5 GHz concurrent)
MIMO Configuration 4x4:4 MU-MIMO (both 2.4 GHz and 5 GHz)
Maximum Data Rate (5 GHz) Up to 1733 Mbps
Maximum Data Rate (2.4 GHz) Up to 600 Mbps
Concurrent Clients Up to 512
Antenna Technology Patented Ruckus BeamFlex+™ Adaptive Antennas
Wired Interfaces Ethernet Port 1 1 x 2.5 Gigabit Ethernet (2.5GbE)
Ethernet Port 2 1 x 1 Gigabit Ethernet (1GbE)
Power over Ethernet (PoE) 802.3af/at (PoE+)
IoT Ready USB Port 1 x USB 2.0 (for BLE, Zigbee modules - modules not integrated)
Physical Dimensions (WxDxH) 22.7 x 21.3 x 6.0 cm (8.9 x 8.4 x 2.4 inches)
Weight Approx. 1.12 kg (2.5 lbs)
Mounting Ceiling, Wall, Desk (mounting bracket included)
Power Power Consumption Max 33.5W (with PoE+)
Power Source 802.3at PoE+ or 12V DC power adapter (sold separately)
Environmental Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -20°C to 70°C (4°F to 158°F)
Operating Humidity Up to 95% non-condensing
Management Deployment Modes SmartZone, Unleashed, ZoneDirector (EOL), Ruckus Cloud, Standalone
Part Number Worldwide Model 901-R720-WW00
