Specifications
Brand Name :
hua wei
Model Number :
AirEngine6760R 51
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
$1800/piece
Payment Terms :
T/T
Delivery Time :
1-3 working day
Part number :
AirEngine6760R 51
Brief Description :
IP68 weatherproof wireless AP
Details :
8×8 MU‑MIMO outdoor AP
Key Features :
5.95 Gbps outdoor Wi‑Fi AP
Condition :
Network Essentials switch
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
Description

AirEngine6760R‑51 Outdoor Wi‑Fi 6 Access Point with Built‑in Smart Antennas

Product Overview
The Huawei AirEngine6760R‑51 is a rugged outdoor Wi‑Fi 6 (802.11ax) access point built for high‑density public and enterprise environments such as stadiums, squares, pedestrian zones, and ports. It features built‑in smart antennas, high surge protection, and versatile uplink options. With IP68 dust and water resistance and industrial‑grade temperature range, it delivers reliable connectivity in extreme conditions.

Product Details

Item Description
Model AirEngine6760R‑51
Wireless Standard Wi‑Fi 6 (802.11ax)
Max Data Rate Up to 5.95 Gbps (combined throughput)
Antenna Type Built‑in directional smart antennas
MIMO 4×4 MU‑MIMO per band (2.4 GHz and 5 GHz)
Ports 1×5GE electrical, 1×GE electrical, 1×10GE SFP+ optical
Bluetooth BLE 5.2
Power Input IEEE 802.3bt PoE
Surge Protection 6 kA/6 kV on Ethernet; built‑in for antenna feeder
Enclosure Rating IP68 dust and water resistance
Operating Temperature –40 °C to +65 °C
Dimensions (H×W×D) 85 mm × 270 mm × 220 mm
Max Users Up to 1024 (varies by environment)

Product Features

Industry‑grade outdoor AP with IP68 and wide temperature tolerance

Built‑in antenna with precise directional coverage and interference reduction

Dual‑radio support: both 2.4 GHz and 5 GHz bands at full 4×4 MU‑MIMO

Extremely fast data rates: up to 4.8 Gbps on 5 GHz, 1.15 Gbps on 2.4 GHz, up to 5.95 Gbps combined

Flexible uplink: support for both electrical (up to 5GE) and 10GE optical interfaces

Strong surge protection and metal shell ensure outdoor resilience

Advanced Wi‑Fi 6 features: OFDMA, UL/DL MU‑MIMO, BSS coloring, TWT for battery efficiency

Smart roaming, load balancing, DFA and EDCA scheduling enhance high‑density user experience

Full security suite with WPA3, WIDS/WIPS, rogue device detection, and wired-wireless dual-layer protection

Product Specifications

Feature Specification
Wi‑Fi Standard IEEE 802.11a/b/g/n/ac/ac Wave 2/ax
Spatial Streams 4×4 on 2.4 GHz and 4×4 on 5 GHz
Max Transmit Power 30 dBm combined per band
Antenna Gain 10 dBi (2.4 GHz), 11 dBi (5 GHz)
Coverage Beamwidth Horizontal: 60°; Vertical: ~40° (2.4 GHz) / ~20° (5 GHz)
SSIDs per Radio Up to 16
MTBF ~92 years (~800,000 hours)
Altitude Range Operates from –60 m to +5000 m
Humidity Support Up to 100 % non‑condensing
Weight 3 kg (~3.1 kg for 51E variant)

Similar Models Comparison

Model Antenna Type Max Rate Max Users Highlights
AirEngine6760R‑51 Built‑in 5.95 Gbps ≤ 1024 Integrated directional smart antennas
AirEngine6760R‑51E External 5.95 Gbps ≤ 1024 External antenna option for long‑range use
AirEngine 6760R‑41 Built‑in Similar High Lower density version
AirEngine 6760R‑21E External Similar High Lower spec alternative outdoor model

Latest Models in Series

Model Release Year Antenna Type Max Rate Highlights
AirEngine6760R‑51 ~2020 Built‑in 5.95 Gbps Industrial outdoor Wi‑Fi 6 AP
AirEngine6760R‑51E ~2020 External 5.95 Gbps External antenna version, built‑in surge
AirEngine6770R‑51E ~2023–2024 External 6+ Gbps Enhanced outdoor Wi‑Fi 6E with higher capacity
