Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Specifications
Model NO. :
WIND-AGWI
Transport Package :
Wooden Case
Specification :
Middle Size
Trademark :
Wind Automation
Origin :
China
HS Code :
8479811000
Production Capacity :
100 Sets/Year
Description
Generator Stator Coil Winding and Coil Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
The machine can do automatically coil winding, coil inserting, wedge inserting by intergrating three machines into one machine. Winding and inserting process are all controlled by servo motor. Auto and jog mode are avaiable.

(1)Features
Two working stations
Easy loading and unloading
High automation and productivity
Fully programmable operation
Parameter adjustable according to different stators
Applied as a stand-alone machine or integrated into a production line
Servo motor control wire arraying and winding, pneumatically shaped to plum blossom,
double work stations automatic position changing,
servo automatic wire embedding, automatically put into slot cover,
one work station for wave shape winding and push into wire embedding mould,
another station for wire embedding and put into slot cover,
put paper inserted stator on the station manually, repeating operation,
PLC control, colorful touching screen, with press work/single step/automatic three kinds of work method,
high automation and efficiency.
(2)Machine configuration
Power supply AC 380V 50HZ
Air pressure 0.5~0.7 MPa
Total power 8KW
Winding speed 10~120r/min
Slots 36/48
Wire range 0.15~1.6mm
Stack length 20~130mm
Dimension 1800mmx1900mmx2500mm


(3)Machine Application
Automatic car automobile Generator alternator stator wave winding and wedge insertion WIND-AGWI is

suitable for auto alternator stator wave shape winding automatic wire winding, automatic wire embedding and putting

into winding transfer former automatically.

WIND-AGWI Fully automatic Double station automatic winding and insertion for alternator generator stator
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
Fully Automatic AC Motor Stator Coil Winding Inserting Machine
