Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe
Specifications
Brand Name :
Huatec
Model Number :
SRT-6350
Certification :
ISO,CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
500 set per month
Delivery Time :
3-7 working days
Packaging Details :
in standard export carton
Product name :
Surface Roughness Tester
Brand :
Huatec
Model :
SRT-6350
Accuracy :
≤±10%
Display :
4 digits, 10 mm LCD, with blue backlight
Power :
Li-ion battery: rechargeable
Description

Highly Sophisticated Inductance Sensor Surface Roughness Tester with SEPARATE PROBE Ra,Rz SRT-6350

Technical parameters:

Parameter Model SRT6200 SRT6350 SRT6210 SRT6400
Tesing range Ra 0.05-10.00um/1.000-400.0uinch 0.005-16.00um/0.020-629.9uinch
Rq 0.005-16.00um/0.020-629.9uinch
Rz 0.020-100.0um/0.780-4000uinch 0.020-160.0um/0.078-6299uinch
Rt 0.020-160.0um/0.078-6299uinch
Accuracy ≤±10%
Resolution 0.001μm if reading ＜10μm; 0.01μm if reading＜100μm; 0.1μm if reading ≥100μm
Display 4 digits, 10 mm LCD, with blue backlight
Fluctuation of display ≤6%
Filter RC, PC-RC,Gauss, D-P
Sensor/pick-up Test Principle Inductance
Radius 10um 5 um
Material Diamond
Measurement Force 16mN(1.6gf) 4mN(0.4gf)
Angle 90°
Vertical Radius of Guiding Head 48mm
Maximum driving stroke 17.5mm/0.7inch
Cutoff length 0.25mm / 0.8mm / 2.5mm optional
Evaluation length 5L
Driving speed sampling length = 0.25mm Vt=0.135mm/s; sampling length = 0.8mm Vt=0.5mm/s; sampling length = 2.8mm Vt=0.5mm/s; returning Vt=1mm/s
Power Li-ion battery: rechargeable
Operating conditions Temp. 0~50℃, Humidity <80%
Weight 420g 350g 420g 350g

Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe

Inductance Sensor Ra Rz Surface Roughness Tester With Separate Probe

Standard delivery:
Carrying case.................1 Operation Manual...........1
Main unit.........................1 Screwdriver.....................1
Standard Sensor.............1 Adjustable Leg................1
Standard Sample Plate...1 Sensor Protector.............1
Power Adapter................1 Calibration certificate 1

Optional accessories:
1. Cable and Software for RS-232/USB and bluetooth
2. Extension Rod
3. Groove stylus
4. Curvature Probe
5. Measurement Stand
