Portable Ceramic X Ray Flaw Detector Radiography NDT Pipeline Welding Checking Machine
Portable Ceramic X Ray Flaw Detector Radiography NDT Pipeline Welding Checking Machine
Specifications
Brand Name :
HUIWEI
Model Number :
RD-3505
Certification :
ISO 9001, CE
Place of Origin :
ZHEJIANG, CHINA
MOQ :
1 set
Price :
17000usd/set
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
500sets within one month
Delivery Time :
15working days
Packaging Details :
Standard export plywood package
Product name :
Industrial x ray testing RD-3505,x-ray welding machine ndt,X-ray Inspection Systems,NDT industrial film processing machine,industrial NDT equipment NDT x ray testing machine
Warranty :
12 Months
Usage :
spaceflight industry, welding engineering industry, shipbuilding industry inspection
Power supply :
AC220V±10%
Application :
Industrial field
Function :
steel defect,NDT inspection welding
Color :
Stainless Steel,Silver gray,blue and white
Max.penetration :
55mm(A3 STEEL)
Film type :
Any kinds of industrial film
Voltage :
170-350kv
Exposure time :
15 minutes
Name :
NDT industrial x-ray machine
Tube current :
5mA
Weight :
34kg
Focus Spot :
2.5*2.5
Generator Weight :
34kg
Description

Portable Ceramic X Ray Flaw Detector Radiography NDT Pipeline Welding Checking Machine

Main introduction:

The RD-3505 is a small, lightweight, compact, portable industrial X-ray flaw detector with strong penetration, time and labor saving, high stability, low failure rate, and continuous 15-minute exposure operation without 1:1 rest. It is suitable for double-wall single-image radiography of chemical tanks and large-diameter pipes, improving work efficiency by 50%.

The equipment is lightweight and portable, with the generator weighing only 34kg, and features a compact design. This series of equipment is available in directional and circumferential versions, with a maximum penetration thickness of 55mm for Q235 steel.

This series of flaw detectors are SF6 gas insulated portable X-ray flaw detectors, which are composed of the following parts:

X-ray generator, intelligent controller, power cable, connecting cable, accessories, etc.

The X-ray generator is a combined structure. The high voltage transformer (including the X-ray tube filament winding) and the X-ray tube are installed in the same tube barrel. The tube barrel is made of aluminum and is sealed. It is filled with sulfur hexafluoride (SF6 is a kind of fluorine chemical product) insulating gas, which has good electrical insulation properties for high voltage.

In order to facilitate the heat dissipation of the X-ray tube, an anode grounding method is adopted. A multi-blade aluminum radiator is installed at the protruding end of the anode target, and a fan is installed on the radiator. The fan is used for forced cooling to enhance the heat dissipation effect. A layer of lead plate for anti-scattering is also laid in the tube barrel.

Secondly, a temperature relay is installed on the iron core in the tube barrel and the external radiator to prevent the machine from being damaged by excessive temperature. There is a flash light power supply for ray warning on the generator, which can be used for ray warning. End rings are installed at both ends of the X-ray generator, allowing it to be placed upright or horizontally for easy transportation.

Application
Oil & Gas
Shipyard building & Building sites
Petrochemical & Power plants
Foundries
Railway parts
Boiler or pressure vessels manufacturers

RD-3505 the technical parameters

Project

RD-3505

input

Input power

Single-phase AC150-250V 50/60Hz

Power supply capacity

No less than 3.0 KVA

output

X - ray tube voltage

170~ 350 KVp

X ray tube current

5mA

mA Stability degree

± 1%

Ray tube

Focal size

2.5× 2.5

X-ray irradiation range

40±5°

Ray generator

working pressure

Cooling mode

Insulation way

0.35MPa ~ 0.5Mpa

Anode ground connection radiator Strong wind cold

Gas insulation SF6

Size

weight (kg)

φ320×640

34

Maximum penetration

Thickness steel A3(mm)

55 mmFe(5 min)

condition

focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5

sensitivity

superior 2%

controller

Size

weight

Circuit

325×270×180

< 9(kg)

Automatic control and protection

Environment

working temperature relative humidity

Altitude

-30°~ +40°

Not more than 85%

Not higher 1500m

methods

fully automatic 4:1 Work and rest,Longest continuous exposure time 15mins
