Lead-Free HASL Double Sided PCB with FR4 Flame-Retardant Material and Customized Silkscreen
Lead-Free HASL Double Sided PCB with FR4 Flame-Retardant Material and Customized Silkscreen
Specifications
Brand Name :
Xingqiang
Model Number :
As Per Customer's Model
Place Of Origin :
China
Certification :
ISO 9001 / ROHS /UL / IATF 16949 (automotive)
MOQ :
Sample,1 Pc(5 Square Meters)
Price :
Based On Gerber
Packaging Details :
As Per Customer's Request
Delivery Time :
NA
Payment Terms :
T/T,Western Union
Supply Ability :
100000㎡/Month
Custom PCB Type :
Double Sided PCB
Copper Wall Thickness :
1OZ
Routing :
0.1mm
Min Line Width :
3 mil
Tg Value :
130-140
Max Board Size :
528*600mm
Quotation :
Gerber Files
Soldermask :
Green or Customized
Silkscreen :
Yellow,White,Black,Red
Special Tech :
Impedance Control ;±10% or +/-5%
Description
Lead-Free HASL Double Sided PCB FR4 Flame-Retardant Material for Station LED Application
What is Double Sided PCB?

The Double Sided PCB is a highly reliable and efficient solution designed to meet the demands of modern electronic applications. Featuring two conductive copper layers, this Dual Sided PCB offers enhanced circuit density and improved electrical performance compared to single-sided boards. The use of advanced materials and manufacturing techniques ensures that the Double Sided PC Board delivers superior durability and functionality, making it an ideal choice for a wide range of industries including telecommunications, automotive, consumer electronics, and industrial control systems.

Technical Parameters
Product Name Custom Double Sided PCB
Oem Service Yes
Min Hole Size 0.1mm
Copper Wall Thickness 1OZ
Board Thickness 0.2-5.0mm
Layer Counts 2L,4L,6L,8L,8L+
Impedance Control +/-10% or +/-5%
Profiling Punching Profiling Punching
Hole Size Tolerance PTH ±0.075, NTPH ±0.05
Solder Mask Green/ White/ Black/ Blue/ Yellow/Red
Custom Double Sided PCB Manufacturing Steps
  • Receive and verify customer Gerber files, drawings and technical requirements.
  • Confirm PCB specifications including FR4 material, layer count and lead-free HASL process.
  • Conduct circuit board production in strict accordance with approved customer documents.
  • Perform electrical testing, functional verification and quality inspection.
  • Ensure full compliance with RoHS, ISO 9001 and international certification standards.
  • Arrange prototype sampling or mass production after customer confirmation.
  • Deliver qualified custom LED station PCBs with stable performance and reliable quality.
