12 SWG ACSR Wire Overhead Line Conductor ACSR Far East Cable
12 SWG ACSR Wire Overhead Line Conductor ACSR Far East Cable
Specifications
Brand Name :
MingTong
Model Number :
OPGW
Certification :
ISO
Place of Origin :
Dong Guan China
Price :
500-5000RNB/KM
Payment Terms :
L/C, T/T
Supply Ability :
200km/Day
Delivery Time :
It depends on the actual situation.
MOQ :
20km
Packaging Details :
Wooden scroll + cardboard box / Wooden scroll + wooden board
Name :
OPGW Cable
Application :
Replacemnet Of Aerial Ground Wire
Fiber :
G652D, G657A1, G657A2
Type :
Professional Manufactures
Cable Diameter :
9-18.2mm
Package :
Iron-wooden Reel
Highlight :
12 Swg Acsr Wire, 12 Swg Acsr Overhead Line Conductor, Acsr Far East Cable
Description
Product Description

12 Swg Acsr Wire Overhead Line Conductor Acsr Far East Cable

Application Features

ABC systems are used in city power grid transmission lines, with an operating voltage of up to 600/1000 volts. They are mainly used for overhead single-phase and three-phase electricity distribution, as well as other purposes. They have a stable working temperature range of -10°C to 80°C and are economical, with good electrical properties and a lower cost than copper cables. They are also flexible and easy to install, making them suitable for distribution and other applications. They provide safety by preventing electric short circuits and potential fire risks, while being durable against UV radiation, moisture, and corrosion. Additionally, they have an aesthetically pleasing finish and are adaptable to the physical properties and electrical needs of the African environment and market.

Specifications

Conductor Technical Structure
Unit
Value



Structure
Center: steel wire



Nos./mm
1/2.0
Layer 1:steel wire
6/2.0
Layer 2: Aluminum wire
10/2.57
Layer 3: Aluminum wire
16/2.57
Standard
/
GB/T1179/IEC 61089/ASTM B232 / B232M-2009 / B498
Stranding direction of outer layer
Direction
Right-hand
Conductor diameter
mm
16.28±1％
Cross section
mm2
156.8±1％
Conductor weight
kg/km
547.8±1％
Rated tensile strength
kN
52
Modulus of Elasticity
GPa
73.9
Coefficient of linear expansion
10-6/℃
18.9
Max. DC Resistance at 20℃
Ohm/ft
0.637

Lay ratio
Aluminum layer

times
16-wire layer 10-14
10-wire layer 10-16
Steel layer
6-wire layer 18-30
Properties of Aluminum Wire (Before Stranding)
Unit
Value
Diameter and tolerance
mm
2.57±0.03
Min. tensile strength
MPa
175
Min. elongation at 250mm
%
1.7
Max. resistivity at 20℃
Ω·mm2/m
0.028172
Properties of Steel wire (Before stranding)
Unit
Value
Diameter and tolerance
mm
2.0±0.02
Min. tensile strength
MPa
1410
Min. tension at 1% elongation
MPa
1280
Min elongation at 250 mm
%
3.5
Class of zinc coating
/
Class A

Zinc coating quality
g /mm²
230
Conductor diameter
MM
6.0
Rated tensile strength
KN
/

Packing & Shipping & Payment
