6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath
6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath
6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath
6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath
Specifications
Brand Name :
MingTong
Certification :
ISO
Place of Origin :
Dongguan CHINA
Price :
500-3000RNB/KM
Payment Terms :
L/C, T/T
Supply Ability :
200km/Day
Delivery Time :
It depends on the actual situation
MOQ :
20km
Packaging Details :
Wooden scroll + cardboard box / Wooden scroll + wooden board
Application :
FTTH, Indoor Wiring System,LAN
Fiber Type :
G657A1 Or A2, G652D
Strength Member :
Steel Wire
Sheath Material :
PE
Highlight :
Highlight: FTTH Indoor Fiber Cable, Butterfly Shaped Indoor Fiber Cable, Butterfly indoor fiber optic cable
Loose Tube Material :
PBT Or Jelly
Waterblocking Material :
Water Blocking Tape Or Filling Compound
Name :
Outdoor Optical Cable
Description
Product Description

Outdoor Non-Metallic Mutil-Core Sm Strength Member Fiber Optical Cable

6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath


Product Description
This Outdoor Double Armoured Optic Fiber Cable are suitable for installation in harsh environments where mechanical impact on the cable is to be expected. E. G. Direct buried opplication. Outdoor Double Armoured Optic Fiber Cable are also suitable for installation in ducts where the rodent resistance is to be expected or the moisture resistance is expected.
Features
Excellent optical, mechanical & environmental performance
Moisture-proof & roden-proof
High strength-to-weight ratio
High tensile strength
High crush strength
Corrosion resistance
Very flexible bending radius
Application
Long haul / backbone application
Direct-burial, duct installation

6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath


Technical data


Technical data
Fiber Num. Outer diameter (mm) Weight (kg/km) Min.Bending radius(mm) Tension (N) Crash loading (N/100mm)
Static Dynamic Short term Long term Short term Long term
2-24 12.6 185 12.5 times O.D. 25 times O.D. 3000 1000 3000 1000
26-36 12.9 195
38-60 13.4 200
62-72 13.9 230
74-96 15.5 275
98-120 17 320
122-144 18.4 365
146-216 18.9 385
218-240 22.1 495
242-288 24.3 580


Our Quality & Service
DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:
1. Consistently meeting for product quality and performance;
2. Timely delivery of products and services to meet our customer's requirements;
3. Ensuring that our people are properly trained so that they are better able to serve our customers.


Our Certificate & FAQ
REACH,ROHS,TLC Telecom Certificate,Environmental Management System Certification,ISO9001:2000,Utility Model Patent Certificate

6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath

Company Profile


As professioanl manufacturer on optical fibre cables, we can not only offer you optical fibre cables with high quality and competitive price, but also the structures as your requirment. So please feel free to contact with us for cooperation and excellent service.

6 Core Outdoor Fiber Optic Cable Single Mode Direct Buried With PE Outer Sheath
Contact with me for this Outdoor Double Armoured Optic Fiber Cable.
