12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
12V 5Ah Highway Commuter Motorcycle For City Commute Horizontal Air Cooled
Specifications
Brand Name :
ZFYC
Model Number :
XY1-SR
Place of Origin :
CHINA
MOQ :
200
Price :
Price negotiable
Payment Terms :
L/C,T/T
Supply Ability :
1000Unit/Month
Delivery Time :
5-12 weeks
Packaging Details :
CKD,SKD,CBU
Engine Type :
Single-cylinder, horizontal, air-cooled
Displacement :
107 cc
Max. Power :
5.2 kW @ 8,000 ± 500 rpm
Max. Torque :
7.2 N·m @ 5,000 ± 500 rpm
Transmission :
4-speed, semi-automatic clutch
Helmet Box Capacity :
Half-face helmet
Description
Reliable 107cc Air-Cooled Motorcycle
Reliable 107cc Air-Cooled Motorcycle with 9.1:1 Compression Ratio, 1255mm Wheelbase, 140mm Ground Clearance, 150kg Max Load Capacity, Halogen Lighting System & Maintenance-Free 12V 5Ah Battery
Engineered for optimal performance and comfort, this 107cc motorcycle features a 9.1:1 compression ratio, 1255mm wheelbase, and 140mm ground clearance. With a maximum load capacity of 150kg, halogen lighting system, and maintenance-free 12V 5Ah battery, it delivers reliable transportation for daily commuting and short trips.
The 780mm seat height is specifically designed for Asian body types, reducing rider fatigue during extended journeys. The integrated half-face helmet storage compartment provides convenient gear storage without additional accessories.
Key Features
  • 107cc single-cylinder air-cooled engine
  • 9.1:1 compression ratio for efficient performance
  • 1255mm wheelbase for stable handling
  • 140mm ground clearance for varied terrain
  • 150kg maximum load capacity
  • Halogen lighting system for enhanced visibility
  • Maintenance-free 12V 5Ah battery
  • Electric & kick start system
  • 4-speed semi-automatic transmission
  • Aluminum wheels and rear carrier
Technical Specifications
Item Specification
Engine Type Single-cylinder, horizontal, air-cooled
Displacement 107 cc
Compression Ratio 9.1 : 1
Max. Power 5.2 kW @ 8,000 ± 500 rpm
Max. Torque 7.2 N*m @ 5,000 ± 500 rpm
Starting System Electric & kick start
Transmission 4-speed, semi-automatic clutch
Final Drive Chain drive
Front Suspension Telescopic hydraulic fork
Rear Suspension Dual shock absorbers
Front Brake Drum brake
Rear Brake Drum brake
Front Tire 2.50-17 (M031 tread pattern)
Rear Tire 2.75-16 (M034 tread pattern)
Overall Dimensions 1920 * 720 * 1140 mm
Wheelbase 1255 mm
Seat Height 780 mm
Ground Clearance 140 mm
Net Weight 93 kg
Max. Load Capacity 150 kg
Max. Speed 78 km/h
Climbing Ability ≥ 22°
Fuel Tank Capacity 3.1 L
Headlight Halogen bulb, 12V 35W
Taillight Halogen bulb, 12V 21W / 5W
Battery 12V 5Ah, maintenance-free
Custom motorcycle orders accepted
