Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Specifications
Brand Name :
NAIKE CHEMICAL
Model Number :
NK-PSR-002
Certification :
ISO
Place of Origin :
Jiangxi, China
MOQ :
1.0 Cubic Meter/Cubic Meters (Min. Order)
Price :
usd100-usd300
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A
Supply Ability :
100 Cubic Meter/Cubic Meters per Week
Delivery Time :
5-8 work day
Packaging Details :
Plastic woven bag with pallets
Processing Service :
Moulding, Cutting
Application :
Chlorine and Bromine Production Plants
Usage :
Chlorine and Bromine Production Plants
Color :
White
Product name :
Snowflake ring
Size :
90mm, 95mm
Material :
PP or other plastic material
Description
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Description
Plastic snowflake ring is a kind of random tower packing. with a large porosity, heat resistance, chemical corrosion, pressure drop and mass transfer unit height is low, high flooding point, vapor-liquid contact with the full, the proportion of small, mass transfer and high efficiency. Used in a variety of medium temperature of 60-150 degrees Celsius.
Product Properties
Item
Data
Plastic
Intalox Snowflake
Ring
DxHxT
Number per m3
Weight
Surface Area
Free Volume
(mm)
(pcs)
(kg/m3)
(m2/m3)
(%)
95x34x1.5
5500
49.5
138
97
Application
- Chlorine and Bromine production plants- HCl absorption in various processes
- Emergency scrubbers
- Environmental scrubbers and strippers
- Air and water coolers in air separation plants
Package
1m3/Supersack , 20m3/20GP, 40m3/20GP. Customize package accepted.
Material
polyethylene (PE), polypropylene (PP), reinforced polypropylene (RPP), polyvinyl chloride (PVC), chloridized polyvinyl chloride
(CPVC) and polyvinylidene fluoride (PVDF).
Delivery Time
10 days for 1X20GP quantity, please check best delivery time with our staff.

Physical & chemical properties of plastic random packing

Performance / Material PE PP RPP PVC CPVC PVDF
Density (g/cm3) 0.94-0.96 0.89-0.91 0.93-0.94
 1.32-1.44 1.50-1.54 1.75-1.78
Operation Temp. 90 >100 >120 >60 >90 >150
Chemical corrosion resistance Good Good Good Good Good Good
Compression Strength(Mpa) >6.0 >6.5 >7.0 >6.0 >8.0 >10.0

Plastic snowflake ring Features:

superior separation efficiency and high capacity. large flux,Incresed Efficiency: Exceptional wetting properties permit large variation in liquid flow rates Low pressure drop,Reduced Energy Consumption: Low pressure drops facilitate smaller fans and lower power consumption Exceptional Chemical Resistance: Moulded in virgin polypropylene and HDPE material. Also available in other engineering thermoplastics for critical applications. Outstanding Strength ,Durability: Thanks to it's distinctive structure it is extraordinarily robust exhibiting unbeatable qualities of stability and resilience. light weight
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants

Plastic Material: 100% virgin PP granules

Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants

Other plastic random packing products
Plastic Snowflake Ring Tower Packing 90mm For Chlorine and Bromine Production Plants
